Tilted Coverflow3D coverflow card carousel of seven tilted photos.
drag, click, or use the arrow keys
'use client'
// npm install framer-motion
import { useCallback, useEffect, useRef, useState } from 'react'
import { motion, type PanInfo } from 'framer-motion'
// ─── Types ────────────────────────────────────────────────────────────────────
interface Slide {
id: number
caption: string
image: string
}
// ─── Data ─────────────────────────────────────────────────────────────────────
// Atmospheric Unsplash photos paired with each wellness theme. The `?w=600&h=750`
// query string asks Unsplash to deliver a portrait crop, keeping the 4:5 aspect
// of every card crisp at the rendered size.
const SLIDES: Slide[] = [
{
id: 0,
caption: 'Alley Sentinel',
image:
'https://images.unsplash.com/photo-1550532422-378e93ec379c?w=600&h=750&fit=crop&auto=format',
},
{
id: 1,
caption: 'Sticker Riot',
image:
'https://images.unsplash.com/photo-1700222720939-60f0e91d691d?w=600&h=750&fit=crop&auto=format',
},
{
id: 2,
caption: 'Quiet Vandals',
image:
'https://images.unsplash.com/photo-1597355797858-35ffba85673c?w=600&h=750&fit=crop&auto=format',
},
{
id: 3,
caption: 'Soft Beast',
image:
'https://images.unsplash.com/photo-1612486524816-d7aaa8ac7bd6?w=600&h=750&fit=crop&auto=format',
},
{
id: 4,
caption: 'City Gaze',
image:
'https://images.unsplash.com/photo-1644424428722-b6f950e4b22d?w=600&h=750&fit=crop&auto=format',
},
{
id: 5,
caption: 'Loud Letters',
image:
'https://images.unsplash.com/photo-1581010105372-caf9ed5ab50f?w=600&h=750&fit=crop&auto=format',
},
{
id: 6,
caption: 'Color Crash',
image:
'https://images.unsplash.com/photo-1589236095092-1f7ea6f09cdd?w=600&h=750&fit=crop&auto=format',
},
]
// ─── Layout constants ─────────────────────────────────────────────────────────
// A flat horizontal fan with a size gradient: the focused center card is the
// largest, and every step outward shrinks the next card. Cards share a single
// base width — the visual scale comes from Framer Motion's `scale` prop, so
// the layout math operates on the same baseline for every card. Horizontal
// positions are computed by walking outward from the center and adding half
// of each neighbour's scaled width plus a constant pixel gap, so adjacent
// cards never overlap.
const TOTAL = 7
const HALF = 3 // |offset| range for stagger math
const ROTATION_PER_STEP = 14 // degrees per offset step
const ARC_Y = 8 // px of vertical arc per |offset| (outer cards drop)
const GAP_PX = 30 // constant visible pixel gap between adjacent cards
const SCALE_BY_OFFSET = [1.0, 0.88, 0.76, 0.64] // index = |offset|
// Runtime transitions (drag, click, key) — snappy, no bounce.
const SPRING = { type: 'spring' as const, stiffness: 240, damping: 30 }
// Mount entrance — slightly bouncier so the focus card has a satisfying settle.
const MOUNT_SPRING = { type: 'spring' as const, stiffness: 180, damping: 18 }
const STAGGER_MS = 0.09
// Wrap-around offset so the 7-card fan always shows 3 left + 1 center + 3 right.
// Without this, cards at the start of the array would drift to offsets like -4/-5
// once focus advances and fall outside the visible fan. By looping any out-of-range
// offset by +/- TOTAL, the leftmost card re-enters from the right edge (and vice
// versa) the instant focus crosses a boundary, keeping the fan perfectly balanced.
function visibleOffset(cardIndex: number, focus: number, total: number) {
const half = Math.floor(total / 2)
let off = cardIndex - focus
if (off > half) off -= total
if (off < -half) off += total
return off
}
function buildXPositions(scales: number[], baseWidth: number, gap: number) {
// scales: array indexed 0..3 by |offset|, scales[0] = center
// returns: Map<offset, translateXPx>, offset in -3..3
const positions = new Map<number, number>()
positions.set(0, 0)
let cursor = 0
for (let i = 1; i <= 3; i++) {
// distance from previous card's center to this card's center
const step = (scales[i - 1] / 2 + scales[i] / 2) * baseWidth + gap
cursor += step
positions.set(i, cursor)
positions.set(-i, -cursor)
}
return positions
}
// ─── TiltedCoverflow ──────────────────────────────────────────────────────────
export default function TiltedCoverflow() {
const [focus, setFocus] = useState(3) // start with the middle slide
const [maxSide, setMaxSide] = useState(3)
const [cardWidth, setCardWidth] = useState(180)
const [mounted, setMounted] = useState(false)
const cardRef = useRef<HTMLButtonElement | null>(null)
// Flip on after first paint so the entrance transition runs once,
// then every subsequent state change uses the snappy runtime spring.
useEffect(() => {
setMounted(true)
}, [])
// Collapse to 1 visible side card under 640px wide.
useEffect(() => {
if (typeof window === 'undefined') return
const mq = window.matchMedia('(min-width: 640px)')
const apply = () => setMaxSide(mq.matches ? 3 : 1)
apply()
mq.addEventListener('change', apply)
return () => mq.removeEventListener('change', apply)
}, [])
// Measure the rendered card width so translateX scales with viewport.
useEffect(() => {
if (typeof window === 'undefined') return
const measure = () => {
if (cardRef.current) {
const w = cardRef.current.getBoundingClientRect().width
if (w > 0) setCardWidth(w)
}
}
measure()
const ro = new ResizeObserver(measure)
if (cardRef.current) ro.observe(cardRef.current)
window.addEventListener('resize', measure)
return () => {
ro.disconnect()
window.removeEventListener('resize', measure)
}
}, [])
const step = useCallback((dir: 1 | -1) => {
setFocus((current) => {
const len = SLIDES.length
return (current + dir + len) % len
})
}, [])
// Arrow keys cycle focus.
useEffect(() => {
const handler = (event: KeyboardEvent) => {
if (event.key === 'ArrowRight') {
event.preventDefault()
step(1)
} else if (event.key === 'ArrowLeft') {
event.preventDefault()
step(-1)
}
}
window.addEventListener('keydown', handler)
return () => window.removeEventListener('keydown', handler)
}, [step])
const handleDragEnd = useCallback(
(_: unknown, info: PanInfo) => {
const distance = info.offset.x
const velocity = info.velocity.x
if (distance < -80 || velocity < -500) {
step(1)
} else if (distance > 80 || velocity > 500) {
step(-1)
}
},
[step],
)
return (
<div className="flex min-h-screen w-full select-none items-center justify-center overflow-hidden bg-[#E8E8DF] px-4 py-12 dark:bg-[#1A1A19]">
<div className="relative flex w-full max-w-5xl flex-col items-center gap-8">
<motion.div
className="relative flex w-full items-center justify-center"
style={{ perspective: '1400px', height: 'clamp(280px, 36vw, 380px)' }}
drag="x"
dragConstraints={{ left: 0, right: 0 }}
dragElastic={0.15}
onDragEnd={handleDragEnd}
>
{(() => {
const positions = buildXPositions(SCALE_BY_OFFSET, cardWidth, GAP_PX)
return SLIDES.map((slide) => {
const offset = visibleOffset(slide.id, focus, TOTAL)
const absOffset = Math.abs(offset)
const hidden = absOffset > maxSide
const isFocus = offset === 0
// Size gradient + spaced fan: scale comes from |offset|, rotateY
// tilts side cards inward, translateX is precomputed so adjacent
// cards keep a constant pixel gap, translateY adds a gentle arc.
const scale = SCALE_BY_OFFSET[absOffset] ?? 0.6
const rotateY = -offset * ROTATION_PER_STEP
const translateX = positions.get(offset) ?? 0
const translateY = absOffset * ARC_Y
// Stagger entrance: outermost cards land first, focus card last.
// |offset|=3 → 0s, 2 → 0.09s, 1 → 0.18s, 0 → 0.27s. After mount,
// every transition uses the runtime spring with no delay.
const mountDelay = (HALF - absOffset) * STAGGER_MS
const transition = mounted
? SPRING
: { ...MOUNT_SPRING, delay: mountDelay }
// Breathing loop: each card drifts on its own period, picture-frame
// swing (rotateZ), small amplitude so caption text stays legible.
const breathDuration = 7 + slide.id * 0.6
// Caption split — word-by-word entrance only for the focused card.
// Non-focused cards render plain spans so swiping doesn't flicker.
const words = slide.caption.split(' ')
return (
<motion.button
key={slide.id}
ref={slide.id === 0 ? cardRef : undefined}
type="button"
aria-label={slide.caption}
onClick={(event) => {
event.preventDefault()
if (!hidden && !isFocus) setFocus(slide.id)
}}
className="absolute aspect-[4/5] w-[clamp(160px,17vw,220px)]"
style={{
transformStyle: 'preserve-3d',
transformOrigin: 'center center',
pointerEvents: hidden ? 'none' : 'auto',
cursor: isFocus ? 'grab' : 'pointer',
zIndex: TOTAL - absOffset,
}}
initial={{ opacity: 0, scale: 0.45, y: 70, x: 0, rotateY: 0 }}
animate={{
x: translateX,
y: translateY,
rotateY,
scale,
opacity: hidden ? 0 : 1,
}}
transition={transition}
whileTap={isFocus ? { cursor: 'grabbing' } : undefined}
>
{/* Middle breathing layer. Owns the visual chrome (rounded
corners, overflow clip, ring, shadow) so the entire card
moves as one unit — no interior translation that could
expose the outer button's background. The image and caption
fill this layer edge-to-edge. */}
<motion.div
className="relative h-full w-full overflow-hidden rounded-[20px] ring-1 ring-black/10 dark:ring-white/10"
style={{
boxShadow: isFocus
? '0 30px 60px rgba(0,0,0,0.35), 0 12px 24px rgba(0,0,0,0.18)'
: '0 14px 30px rgba(0,0,0,0.22), 0 4px 10px rgba(0,0,0,0.12)',
}}
animate={{
y: [0, -12, 0, 10, 0],
rotate: [0, 1.5, 0, -1.5, 0],
}}
transition={{
duration: breathDuration,
repeat: Infinity,
ease: 'easeInOut',
}}
>
<img
src={slide.image}
alt={slide.caption}
loading="lazy"
draggable={false}
className="absolute inset-0 h-full w-full object-cover"
/>
{/* Caption with soft gradient fade into the photo. No border,
no backdrop-blur, no pill — text reads like an album-art
title that's been laid into the image. */}
<div className="pointer-events-none absolute inset-x-0 bottom-0 flex flex-col justify-end px-4 pb-3 pt-12">
<div
aria-hidden
className="absolute inset-x-0 bottom-0 h-2/3"
style={{
background:
'linear-gradient(to top, rgba(0,0,0,0.78) 0%, rgba(0,0,0,0.55) 35%, rgba(0,0,0,0.18) 70%, rgba(0,0,0,0) 100%)',
}}
/>
<span
className="relative text-center leading-tight text-white font-medium"
style={{
fontSize: 'clamp(0.95rem, 1.1vw, 1.25rem)',
textShadow: '0 1px 8px rgba(0,0,0,0.45)',
}}
>
{isFocus
? words.map((word, i) => (
<motion.span
key={`${focus}-${i}`}
className="inline-block"
initial={{ opacity: 0, y: 8 }}
animate={{ opacity: 1, y: 0 }}
transition={{
delay: i * 0.06,
duration: 0.42,
ease: [0.2, 0.65, 0.3, 1],
}}
>
{word}
{i < words.length - 1 ? ' ' : ''}
</motion.span>
))
: words.map((word, i) => (
<span key={i} className="inline-block">
{word}
{i < words.length - 1 ? ' ' : ''}
</span>
))}
</span>
</div>
</motion.div>
</motion.button>
)
})
})()}
</motion.div>
{/* Dot indicator + hint */}
<div className="flex flex-col items-center gap-3">
<div className="flex items-center gap-1.5">
{SLIDES.map((slide) => {
const isCurrent = focus === slide.id
return (
<motion.button
key={slide.id}
type="button"
aria-label={`Focus ${slide.caption}`}
onClick={() => setFocus(slide.id)}
animate={{
width: isCurrent ? 22 : 6,
opacity: isCurrent ? 1 : 0.35,
}}
transition={{ type: 'spring', stiffness: 400, damping: 30 }}
className="h-1.5 rounded-full bg-[#21211F] dark:bg-[#FAFAF0]"
/>
)
})}
</div>
<p className="text-xs tracking-wide text-[#666662] dark:text-[#9E9E98]">
drag, click, or use the arrow keys
</p>
</div>
</div>
</div>
)
}
Add to your project
One command adds this component to your project.
Run the following command. New project? Run npx shadcn@latest init first to set up Tailwind and path aliases.
npx shadcn@latest add @aicanvas/tilted-coverflowFor dark mode, add the dark class to your <html> element:
<html class="dark">Install with AI Canvas MCP
With AI Canvas MCP, your AI knows every component we ship. Ask for “a navigation component from AI Canvas” inside Claude Code, Codex, or Cursor and it can suggest you a few options, then install the one you like. Less typing, lower token cost, modern way to build.
Get MCPAbout Tilted Coverflow
Tilted Coverflow is a 3D photo carousel built on CSS perspective and rotateY transforms, not Three.js. Seven cards fan out in a horizontal arc with a size gradient from center to edge; every card breathes on its own slow loop, and the focused caption fades in word by word when it lands in the middle. Drag, click any side card, or use the arrow keys to focus, and the row wraps circularly so three cards always sit on each side of center. Motion handles the springs and breathing; Tailwind covers layout. Suits portfolios, image galleries, or hero bands that want a tactile, image-forward interaction.
