Radial CardsSeven health-metric cards bloom into a slowly rotating flower — tap any petal to pull it forward and read your stats up close.
'use client'
// npm install framer-motion @phosphor-icons/react react
import { useEffect, useRef, useState, type ComponentType, type RefObject } from 'react'
import type { CSSProperties, PointerEvent as ReactPointerEvent } from 'react'
import {
animate,
motion,
useAnimationFrame,
useMotionValue,
useMotionValueEvent,
useSpring,
useTransform,
type MotionValue,
} from 'framer-motion'
import { Footprints, Fire, Moon, Drop, Heart, Lightning, Path } from '@phosphor-icons/react'
// ─── Theme + tuning constants ────────────────────────────────────────────────
const SECONDS_PER_TURN = 45
const REDUCED_SECONDS_PER_TURN = SECONDS_PER_TURN * 4 // 1/4 speed when reduced
const ENGAGED_LIFT_Z = 120
const REDUCED_LIFT_Z = 30
const ENGAGED_SCALE = 1.18
const REDUCED_ENGAGED_SCALE = 1.06
// Lift/scale/centering — softer, glide-forward feel (no flip snap).
const LIFT_SPRING = { stiffness: 140, damping: 28, mass: 1 } as const
// Redistribution (slot angle, idle rotation factor, skew, outward) — softened
// slightly so the post-click rearrangement glides instead of snapping.
const SPRING = { stiffness: 200, damping: 24, mass: 1 } as const
const SPEED_SPRING = { stiffness: 90, damping: 20, mass: 1 } as const
// Card dimensions.
const CARD_W = 240
const CARD_H = 138
// Petal tilt — slight skew so the rectangle reads as a slightly off-rectangular
// petal in the bouquet, matching the reference image.
const PETAL_SKEW_Y = 0
// Outward push from the shared anchor — set to 0 per the Figma redesign so all
// 7 cards converge at a single anchor point with no perimeter ring. The
// centeringFactor interpolation collapses on the slot side to translate(-50%,
// -100%) — cards sit with their bottom-centre exactly at the anchor.
const OUTWARD_OFFSET_PX = '0px'
// Hand-arranged slot angles for the 7-card bouquet, in clockwise order
// starting from the upper-right (Steps).
const SLOT_ANGLES: readonly number[] = [
-35.55, // 0 Steps
22.14, // 1 Calories
71.01, // 2 Sleep
122.25, // 3 Water
161.58, // 4 Heart
-150.4, // 5 Active
-108.41, // 6 Distance
]
// Stage that holds the bouquet. With BL pivot, cards extend up-and-right from
// the shared anchor at the canvas centre. The bouquet bounding box is roughly
// 2 × max(W, H) ≈ 560px, so the clamp gives some breathing room around the
// rotated bouquet without clipping.
const STAGE_SIZE = 'clamp(300px, 50vw, 560px)'
// ─── 7 metrics + theme palette ───────────────────────────────────────────────
type PhosphorIconProps = {
size?: number | string
weight?: 'thin' | 'light' | 'regular' | 'bold' | 'fill' | 'duotone'
color?: string
}
type Metric = {
title: string
label: string
value: string
delta: string
/** Pastel card gradient start (top). */
surface: string
/** Deeper gradient end (bottom). */
gradientEnd: string
/** Dark variant — used for metric value, pill bg, sparkline stroke. */
dark: string
/** 7 y-values (px, 0=top 31=bottom) for the sparkline in viewBox 0 0 108 31. */
sparkline: readonly number[]
/** Phosphor icon for the header. */
Icon: ComponentType<PhosphorIconProps>
}
const METRICS: Metric[] = [
{
title: 'Steps',
label: 'TODAY',
value: '20.5K',
delta: '+5K',
surface: '#EAF6AE',
gradientEnd: '#ACC13C',
dark: '#5C662A',
sparkline: [28, 18, 10, 6],
Icon: Footprints,
},
{
title: 'Calories',
label: 'BURNED',
value: '1,820',
delta: '+120',
surface: '#F9C8A7',
gradientEnd: '#D4783A',
dark: '#853C0B',
sparkline: [30, 8, 20, 6],
Icon: Fire,
},
{
title: 'Sleep',
label: 'LAST NIGHT',
value: '7h 42m',
delta: '+18m',
surface: '#C1C2FA',
gradientEnd: '#7B7DF0',
dark: '#363885',
sparkline: [22, 30, 14, 18],
Icon: Moon,
},
{
title: 'Water',
label: 'TODAY',
value: '2.1 L',
delta: '+0.4 L',
surface: '#96D9F7',
gradientEnd: '#4BB8F0',
dark: '#085B80',
sparkline: [26, 14, 20, 4],
Icon: Drop,
},
{
title: 'Heart',
label: 'RESTING',
value: '72 BPM',
delta: '−4',
surface: '#FBB1BE',
gradientEnd: '#F07090',
dark: '#862334',
sparkline: [8, 22, 16, 28],
Icon: Heart,
},
{
title: 'Active',
label: 'THIS WEEK',
value: '48 min',
delta: '+12 min',
surface: '#9BE6DD',
gradientEnd: '#48C7B8',
dark: '#0B655B',
sparkline: [32, 20, 10, 4],
Icon: Lightning,
},
{
title: 'Distance',
label: 'THIS WEEK',
value: '8.4 km',
delta: '+1.2 km',
surface: '#FAD79C',
gradientEnd: '#E8B040',
dark: '#875706',
sparkline: [24, 12, 20, 6],
Icon: Path,
},
]
// ─── Sparkline ───────────────────────────────────────────────────────────────
// Proper Catmull-Rom → cubic bezier conversion for silky-smooth curves.
function SparkLine({ points, color, id }: { points: readonly number[]; color: string; id: string }) {
const W = 54, H = 36
const n = points.length
const xs = points.map((_, i) => (i / (n - 1)) * W)
const pts = points.map((y, i) => ({ x: xs[i], y }))
const segs: string[] = [`M ${pts[0].x},${pts[0].y}`]
for (let i = 0; i < n - 1; i++) {
const p0 = pts[Math.max(0, i - 1)]
const p1 = pts[i]
const p2 = pts[i + 1]
const p3 = pts[Math.min(n - 1, i + 2)]
const cp1x = p1.x + (p2.x - p0.x) / 6
const cp1y = p1.y + (p2.y - p0.y) / 6
const cp2x = p2.x - (p3.x - p1.x) / 6
const cp2y = p2.y - (p3.y - p1.y) / 6
segs.push(`C ${cp1x},${cp1y} ${cp2x},${cp2y} ${p2.x},${p2.y}`)
}
const linePath = segs.join(' ')
const areaPath = `${linePath} L ${W},${H} L 0,${H} Z`
const gradId = `spark-${id}`
return (
<svg width={W} height={H} viewBox={`0 0 ${W} ${H}`} fill="none" style={{ display: 'block', overflow: 'visible' }}>
<defs>
<linearGradient id={gradId} x1="0" y1="0" x2="0" y2="1">
<stop offset="0%" stopColor={color} stopOpacity="0.12" />
<stop offset="100%" stopColor={color} stopOpacity="0" />
</linearGradient>
</defs>
<path d={areaPath} fill={`url(#${gradId})`} />
<path d={linePath} stroke={color} strokeWidth={1.5} strokeLinecap="round" strokeLinejoin="round" />
</svg>
)
}
// ─── Hooks ───────────────────────────────────────────────────────────────────
function useTheme(ref: RefObject<HTMLElement | null>) {
const [theme, setTheme] = useState<'light' | 'dark'>('dark')
useEffect(() => {
const element = ref.current
if (!element) return
const read = () => {
const scope = element.closest('[data-card-theme]') as HTMLElement | null
if (scope) {
setTheme(scope.dataset.cardTheme === 'dark' ? 'dark' : 'light')
return
}
setTheme(document.documentElement.classList.contains('dark') ? 'dark' : 'light')
}
read()
const observers: MutationObserver[] = []
let current: HTMLElement | null = element
while (current) {
const o = new MutationObserver(read)
o.observe(current, { attributes: true, attributeFilter: ['class', 'data-card-theme'] })
observers.push(o)
current = current.parentElement
}
return () => observers.forEach((o) => o.disconnect())
}, [ref])
return { theme }
}
function useReducedMotion(): boolean {
const [reduced, setReduced] = useState(false)
useEffect(() => {
if (typeof window === 'undefined') return
const mq = window.matchMedia('(prefers-reduced-motion: reduce)')
const update = () => setReduced(mq.matches)
update()
mq.addEventListener('change', update)
return () => mq.removeEventListener('change', update)
}, [])
return reduced
}
// ─── Card ────────────────────────────────────────────────────────────────────
type CardProps = {
index: number
metric: Metric
/** Shared idle rotation in degrees. */
rotation: MotionValue<number>
/** Index of the currently engaged card, or null. */
engagedIndex: number | null
/** Index of the most-recently-clicked card, or null. Persists past release. */
topIndex: number | null
/** True when reduced motion is in effect. */
reduced: boolean
onToggle: (index: number) => void
}
function Card({
index,
metric,
rotation,
engagedIndex,
topIndex,
reduced,
onToggle,
}: CardProps) {
const engaged = engagedIndex === index
const isTop = topIndex === index
// ─── Compute the target slot angle ──────────────────────────────────────
// Idle (engagedIndex == null): 7-slot bouquet using the hand-arranged
// SLOT_ANGLES array.
// Someone-else engaged: 6-slot redistribution. j is this card's index in
// the 6-card layout (0..5), computed by skipping the engaged slot.
// Self engaged: slot is irrelevant because centeringFactor=1 collapses
// outwardOffset+rotation contribution; we just feed a placeholder.
// Each card always owns its hand-tuned slot — no redistribution when a sibling engages.
const slotTargetDeg = SLOT_ANGLES[index]
// Per-card springs ──────────────────────────────────────────────────────
const outwardFactorTarget = useMotionValue(1)
const outwardFactor = useSpring(outwardFactorTarget, SPRING)
// Centering uses the softer LIFT_SPRING — it drives the move-to-centre
// glide alongside the lift/scale, so they should share the same easing.
const centeringFactorTarget = useMotionValue(0)
const centeringFactor = useSpring(centeringFactorTarget, LIFT_SPRING)
const skewFactorTarget = useMotionValue(1)
const skewFactor = useSpring(skewFactorTarget, SPRING)
const liftTarget = useMotionValue(0)
const lift = useSpring(liftTarget, LIFT_SPRING)
const scaleTarget = useMotionValue(1)
const scale = useSpring(scaleTarget, LIFT_SPRING)
const opacityTarget = useMotionValue(1)
const cardOpacity = useSpring(opacityTarget, SPRING)
// ─── Per-card rotation MotionValue (shortest-path engagement) ──────────
// This single MotionValue is the actual visual rotation of the card's
// pivot in degrees. It operates in two modes:
//
// FOLLOW mode (default, non-engaged, no transition in flight):
// cardRotation continuously syncs to SLOT_ANGLES[index] + idleRotation.
// Updated via a useMotionValueEvent listener on idleRotation — no
// spring lag, no separate slot spring. Both engaging and releasing
// transitions briefly leave this mode.
//
// SPRING mode (engagement transitions):
// cardRotation is animated by `animate(...)` to a shortest-path
// equivalent of the desired target (engaged: 0; non-engaged: current
// slot+idle). The spring traverses at most 180° in either direction —
// never a full revolution.
//
// The mode is tracked by `followModeRef`. It flips off at engagement
// transitions and back on after the spring lands.
//
// The "follow base" — the slot angle this card tracks while in FOLLOW
// mode — is held in a ref so the listener always reads the latest value
// (it changes when another card engages and redistribution kicks in).
const initialRot = SLOT_ANGLES[index] + rotation.get()
const cardRotation = useMotionValue(initialRot)
const followModeRef = useRef<boolean>(true)
const followBaseRef = useRef<number>(SLOT_ANGLES[index])
// FOLLOW mode listener — when active, cardRotation tracks idle continuously.
// While in spring mode this listener is a no-op (followModeRef.current is
// false), so the running spring is not fought by idle drift.
useMotionValueEvent(rotation, 'change', (latest) => {
if (!followModeRef.current) return
cardRotation.set(followBaseRef.current + latest)
})
// ─── Engagement transition driver ───────────────────────────────────────
// On engagement state change (or redistribution-base change), compute the
// shortest-path equivalent target and animate cardRotation there with
// LIFT_SPRING. After the spring lands (or is interrupted), if we're back
// in non-engaged state, re-enable FOLLOW mode so cardRotation resumes
// tracking idle from the (possibly new) base slot.
useEffect(() => {
// Compute the shortest-path equivalent of `target` relative to `current`.
// Returns a value V such that V ≡ target (mod 360) and |V - current| ≤ 180.
const shortestEquivalent = (current: number, target: number): number => {
let delta = target - current
while (delta > 180) delta -= 360
while (delta <= -180) delta += 360
return current + delta
}
if (engaged) {
// Engaging: spring cardRotation from current slot angle toward 0 (centre).
// The card is at its slot (centeringFactor≈0) so this rotation is visible
// and intentional — it sweeps the card inward along its arc.
followBaseRef.current = 0
followModeRef.current = false
const current = cardRotation.get()
const shortestTarget = shortestEquivalent(current, 0)
const controls = animate(cardRotation, shortestTarget, {
type: 'spring',
...LIFT_SPRING,
})
return () => controls.stop()
} else {
// Releasing: snap rotation instantly to the correct slot+idle angle.
// This is invisible — while centeringFactor=1 the card is centred ON its
// pivot, so rotating the pivot doesn't change the card's screen position.
// The visual return is handled entirely by the centeringFactor/lift/scale
// springs: the card glides straight outward along its slot direction.
followBaseRef.current = slotTargetDeg
cardRotation.set(slotTargetDeg + rotation.get())
followModeRef.current = true
}
// Run when engagement state OR the redistribution slot changes.
// eslint-disable-next-line react-hooks/exhaustive-deps
}, [engaged, slotTargetDeg, index])
// Drive remaining (non-rotation) targets from the engagement model ──────
useEffect(() => {
if (engaged) {
// This is the focused card. Move to centre, lift forward in Z, scale
// up — front face stays visible the whole time. No flip.
outwardFactorTarget.set(0)
centeringFactorTarget.set(1)
skewFactorTarget.set(0)
liftTarget.set(reduced ? REDUCED_LIFT_Z : ENGAGED_LIFT_Z)
scaleTarget.set(reduced ? REDUCED_ENGAGED_SCALE : ENGAGED_SCALE)
opacityTarget.set(1)
} else {
// Petal — either idle or sibling of an engaged card. Same target either
// way (slot-centre with full skew + outward offset + idle rotation).
outwardFactorTarget.set(1)
centeringFactorTarget.set(0)
skewFactorTarget.set(1)
liftTarget.set(0)
scaleTarget.set(1)
// In reduced motion, petals dim slightly when a sibling is engaged.
opacityTarget.set(reduced && engagedIndex != null ? 0.7 : 1)
}
}, [
engaged,
engagedIndex,
reduced,
slotTargetDeg,
outwardFactorTarget,
centeringFactorTarget,
skewFactorTarget,
liftTarget,
scaleTarget,
opacityTarget,
])
// Pivot transform — uses the per-card rotation MotionValue directly.
// FOLLOW mode keeps it tracking SLOT_ANGLES[index] + idle continuously;
// SPRING mode glides it along the shortest path to the engagement target.
const pivotTransform = useTransform(
cardRotation,
(r) => `rotate(${r as number}deg)`,
)
// Card body transform — interpolates between two anchors. The card element
// has transform-origin at its bottom-left (0% 100%), so:
// centeringFactor=0 → bottom-LEFT at the pivot (translate(0, -100%))
// all 7 cards' BL corners coincide at the canvas centre
// centeringFactor=1 → CENTRE on the pivot (translate(-50%, -50%))
// Both translateX and translateY interpolate together via centeringFactor.
// Plus skewY scaled by skewFactor so the engaged card eases to 0° skew.
// outwardFactor multiplies OFFSET (currently 0) for any future radial gap.
const cardBodyTransform = useTransform(
[centeringFactor, skewFactor, outwardFactor],
([c, sk, ow]) => {
const cf = c as number
const skf = sk as number
const owf = ow as number
// X-anchor blend: 0% (BL at pivot) → -50% (centre)
// Y-anchor blend: -100% (BL at pivot) → -50% (centre)
const txPct = -50 * cf
return (
`translate(${txPct}%, calc(-50% - (50% + (${OUTWARD_OFFSET_PX}) * ${owf}) * ${1 - cf})) ` +
`skewY(${PETAL_SKEW_Y * skf}deg)`
)
},
)
// Lift transform — applied to a CHILD wrapper inside the layout transform,
// so the lift comes off the petal's surface in its LOCAL frame (which reads
// as "out of the bouquet" in screen space). translateZ requires the
// ancestors' transform-style: preserve-3d + the stage's perspective.
const liftTransform = useTransform(
[lift, scale],
([z, s]) => `translateZ(${z as number}px) scale(${s as number})`,
)
// Z-index priority (highest to lowest):
// lift > 4 (mid-glide, either lifting or returning) → 50
// currently engaged at rest → 40
// most-recently-clicked card (persists past release) → 30
// default (slot, never clicked OR superseded by a newer) → 1
// The closure captures `engaged` and `isTop` at hook setup time. When state
// changes, the component re-renders and useTransform is re-invoked with the
// fresh closure values; we additionally nudge the underlying MotionValue
// (see useEffect below) so the transform recomputes immediately rather than
// waiting for the next lift change.
const dynamicZIndex = useTransform(lift, (z) => {
if (z > 4) return 50
if (engaged) return 40
if (isTop) return 30
return 1
})
// Force the dynamicZIndex transform to recompute when the booleans change.
// Without this, the zIndex would only update on the next lift spring tick.
useEffect(() => {
lift.set(lift.get())
}, [engaged, isTop, lift])
// Layered drop shadow grows when engaged for the "lifted" feel.
const restShadow =
'4px 6px 14px rgba(0,0,0,0.18), 12px 18px 40px rgba(0,0,0,0.22)'
const liftedShadow =
'8px 14px 26px rgba(0,0,0,0.30), 28px 36px 70px rgba(0,0,0,0.34)'
function handlePointerDown(e: ReactPointerEvent<HTMLDivElement>) {
e.stopPropagation()
onToggle(index)
}
// ─── Face content ──────────────────────────────────────────────────────────
const interStack =
'"Manrope", ui-sans-serif, system-ui, -apple-system, "Segoe UI", sans-serif'
const frontShadow =
'-8px 16px 32px rgba(0,0,0,0.12), -3px 6px 14px rgba(0,0,0,0.18)'
return (
<motion.div
style={{
position: 'absolute',
top: '50%',
left: '50%',
width: 0,
height: 0,
transformOrigin: '0 0',
zIndex: dynamicZIndex,
transformStyle: 'preserve-3d',
transform: pivotTransform,
}}
>
<motion.div
style={{
position: 'absolute',
top: 0,
left: 0,
width: CARD_W,
height: CARD_H,
transformOrigin: '0% 100%',
transformStyle: 'preserve-3d',
transform: cardBodyTransform,
opacity: cardOpacity,
touchAction: 'manipulation',
cursor: 'pointer',
userSelect: 'none',
}}
onPointerDown={handlePointerDown}
>
<motion.div
style={{
position: 'absolute',
inset: 0,
transformStyle: 'preserve-3d',
transform: liftTransform,
}}
>
{/* Outer card shell — gradient + border */}
<div
style={{
position: 'absolute',
inset: 0,
borderRadius: 24,
overflow: 'hidden',
background: `linear-gradient(to bottom, ${metric.surface}, ${metric.gradientEnd})`,
boxShadow: engaged ? liftedShadow : frontShadow,
transition: 'box-shadow 320ms ease',
padding: '12px 4px 4px 4px',
display: 'flex',
flexDirection: 'column',
gap: 10,
fontFamily: interStack,
}}
>
{/* Header — 12px circle bullet + title */}
<div
style={{
display: 'flex',
alignItems: 'center',
gap: 8,
paddingLeft: 6,
paddingTop: 2,
flexShrink: 0,
}}
>
<metric.Icon size={12} weight="regular" color={metric.dark} />
<span
style={{
color: '#1a1a1a',
fontSize: 12,
fontWeight: 500,
lineHeight: 1,
}}
>
{metric.title}
</span>
</div>
{/* Inner panel — cream bg, pill top-right, text+sparkline bottom */}
<div
style={{
flex: '1 0 0',
background: '#f7f7f5',
borderRadius: 20,
padding: 12,
display: 'flex',
flexDirection: 'column',
justifyContent: 'space-between',
boxShadow: '0px 1px 12px rgba(0,0,0,0.25)',
minHeight: 0,
}}
>
{/* Pill — top right */}
<div style={{ display: 'flex', justifyContent: 'flex-end' }}>
<span
style={{
background: metric.dark,
color: '#ffffff',
fontSize: 10,
fontWeight: 600,
padding: '5px 10px',
borderRadius: 999,
lineHeight: 1,
whiteSpace: 'nowrap',
}}
>
{metric.delta}
</span>
</div>
{/* Bottom row — label+value left, sparkline right */}
<div
style={{
display: 'flex',
alignItems: 'flex-end',
justifyContent: 'space-between',
}}
>
<div
style={{
display: 'flex',
flexDirection: 'column',
gap: 2,
}}
>
<span
style={{
color: '#1a1a1a',
fontSize: 10,
fontWeight: 600,
letterSpacing: '0.48px',
lineHeight: 1,
}}
>
{metric.label}
</span>
<span
style={{
color: metric.dark,
fontSize: 23,
fontWeight: 600,
letterSpacing: '-0.28px',
lineHeight: 1,
}}
>
{metric.value}
</span>
</div>
<SparkLine points={metric.sparkline} color={metric.dark} id={String(index)} />
</div>
</div>
</div>
</motion.div>
</motion.div>
</motion.div>
)
}
// ─── Root ────────────────────────────────────────────────────────────────────
export default function RadialCards() {
const rootRef = useRef<HTMLDivElement>(null)
const { theme } = useTheme(rootRef)
const isDark = theme === 'dark'
const reduced = useReducedMotion()
// Shared idle rotation (degrees) — single source for all 7 cards.
const rotation = useMotionValue(0)
// Speed multiplier eases between idle (1) and paused (0) so rotation never
// snaps to a stop when a card engages.
const speedTargetRef = useRef(1)
const speedTarget = useMotionValue(1)
const speedSmooth = useSpring(speedTarget, SPEED_SPRING)
// Engagement state — single source of truth.
const [engagedIndex, setEngagedIndex] = useState<number | null>(null)
// Most-recently-clicked card. Persists across release so the just-released
// card retains a higher zIndex than its untouched neighbours until a
// different card is clicked. Background releases do NOT clear this.
const [topIndex, setTopIndex] = useState<number | null>(null)
// Push speed target whenever engagement changes — petals keep orbiting at
// full speed when nothing is engaged; when something engages, the SHARED
// rotation continues (petals continue), but the engaged card's
// idleRotationFactor=0 keeps it locked relative to the screen.
useEffect(() => {
speedTargetRef.current = 1
speedTarget.set(speedTargetRef.current)
}, [engagedIndex, speedTarget])
// Continuous rotation tick — degrees per second × dt × speed multiplier.
const prevTs = useRef<number | null>(null)
useAnimationFrame((t) => {
const last = prevTs.current
prevTs.current = t
if (last == null) return
const dt = (t - last) / 1000
const seconds = reduced ? REDUCED_SECONDS_PER_TURN : SECONDS_PER_TURN
const degPerSec = 360 / seconds
const next = rotation.get() + degPerSec * speedSmooth.get() * dt
rotation.set(((next % 360) + 360) % 360)
})
function handleToggle(i: number) {
// Every click — engaging OR releasing — marks this card as the top of the
// stack. topIndex is independent of engagement and only changes when a
// different card is clicked.
setTopIndex(i)
setEngagedIndex((prev) => (prev === i ? null : i))
}
function handleStageRelease() {
// Tap outside any card on the stage / root background. Engagement clears,
// but topIndex is intentionally preserved — the last-clicked card keeps
// its top-of-stack status until someone else clicks a different card.
setEngagedIndex(null)
}
return (
<div
ref={rootRef}
className="relative flex min-h-screen w-full items-center justify-center overflow-hidden"
style={{
background: isDark ? '#1A1A19' : '#F0F0E8',
}}
onPointerDown={handleStageRelease}
>
{/* Subtle radial vignette to lift the centre of the bouquet. */}
<div
aria-hidden
style={{
position: 'absolute',
inset: 0,
background:
'radial-gradient(60% 60% at 50% 50%, rgba(255,255,255,0.04) 0%, rgba(255,255,255,0.015) 35%, rgba(0,0,0,0) 70%)',
pointerEvents: 'none',
}}
/>
{/* Perspective stage / bouquet container — clicking the empty stage clears engagement. */}
<div
style={{
position: 'relative',
width: STAGE_SIZE,
height: STAGE_SIZE,
perspective: '1200px',
perspectiveOrigin: '50% 50%',
touchAction: 'manipulation',
}}
>
<div
style={{
position: 'absolute',
inset: 0,
transformStyle: 'preserve-3d',
}}
>
{METRICS.map((metric, i) => (
<Card
key={metric.title}
index={i}
metric={metric}
rotation={rotation}
engagedIndex={engagedIndex}
topIndex={topIndex}
reduced={reduced}
onToggle={handleToggle}
/>
))}
</div>
</div>
</div>
)
}
Add to your project
One command adds this component to your project.
Run the following command. New project? Run npx shadcn@latest init first to set up Tailwind and path aliases.
npx shadcn@latest add @aicanvas/radial-cardsFor dark mode, add the dark class to your <html> element:
<html class="dark">Install with AI Canvas MCP
With AI Canvas MCP, your AI knows every component we ship. Ask for “a navigation component from AI Canvas” inside Claude Code, Codex, or Cursor and it can suggest you a few options, then install the one you like. Less typing, lower token cost, modern way to build.
Get MCPAbout Radial Cards
Radial Cards is a flower of seven health-metric cards arranged around a central hub, slowly rotating so each petal cycles through the foreground. Tap any petal and it pulls forward, scales up, and pauses the rotation so you can read the stats up close; tap again and the bloom resumes. Motion handles both the orbit and the focus-pull. It is a strong fit for health-app dashboards, marketing pages for fitness or wellness products, and any UI where multiple related stats deserve equal billing.
