Upload ProgressA collapsible file upload widget with a shimmer progress bar — indigo while uploading, amber on pause.
Uploading 3 files
0% · 16s left
'use client'
// npm install framer-motion @phosphor-icons/react
import { useState, useEffect, useRef } from 'react'
import { motion, AnimatePresence } from 'framer-motion'
import {
Pause,
Play,
ArrowCounterClockwise,
X,
ArrowsOutSimple,
ArrowsInSimple,
} from '@phosphor-icons/react'
const FILES = [
{ name: 'Brand reel.mp4', durationMs: 8000 },
{ name: 'Product demo.mp4', durationMs: 12500 },
{ name: 'Hero animation.mp4', durationMs: 16000 },
]
type Status = 'uploading' | 'paused' | 'complete' | 'idle'
const SPRING = { type: 'spring' as const, stiffness: 380, damping: 30 }
const CARD_SHADOW = '0px 16px 56px rgba(0,0,0,0.14)'
function useDarkMode(ref: React.RefObject<HTMLElement | null>) {
const [isDark, setIsDark] = useState(false)
useEffect(() => {
const el = ref.current
if (!el) return
const update = () => {
const scope = el.closest('[data-card-theme]') as HTMLElement | null
if (scope) { setIsDark(scope.dataset.cardTheme === 'dark'); return }
setIsDark(document.documentElement.classList.contains('dark'))
}
update()
const obs = new MutationObserver(update)
obs.observe(document.documentElement, { attributes: true, attributeFilter: ['class'] })
return () => obs.disconnect()
}, [ref])
return isDark
}
export default function UploadProgress() {
const rootRef = useRef<HTMLDivElement>(null)
const isDark = useDarkMode(rootRef)
const [status, setStatus] = useState<Status>('uploading')
const [expanded, setExpanded] = useState(false)
const [progress, setProgress] = useState([0, 0, 0])
const progressRef = useRef([0, 0, 0])
const intervalRef = useRef<ReturnType<typeof setInterval> | null>(null)
useEffect(() => {
if (status !== 'uploading') {
if (intervalRef.current) {
clearInterval(intervalRef.current)
intervalRef.current = null
}
return
}
intervalRef.current = setInterval(() => {
const next = progressRef.current.map((p, i) =>
Math.min(100, p + (100 / FILES[i].durationMs) * 80)
)
progressRef.current = next
setProgress([...next])
if (next.every(p => p >= 100)) setStatus('complete')
}, 80)
return () => {
if (intervalRef.current) {
clearInterval(intervalRef.current)
intervalRef.current = null
}
}
}, [status])
useEffect(() => {
if (status !== 'complete') return
const t = setTimeout(() => {
progressRef.current = [0, 0, 0]
setProgress([0, 0, 0])
setStatus('idle')
}, 2000)
return () => clearTimeout(t)
}, [status])
const overallPct = Math.round(progress.reduce((a, b) => a + b, 0) / FILES.length)
const secondsLeft = Math.max(
0,
Math.round(((100 - progress[2]) / 100) * FILES[2].durationMs / 1000)
)
function togglePause() {
setStatus(s => (s === 'uploading' ? 'paused' : 'uploading'))
}
function handleStop() {
if (intervalRef.current) clearInterval(intervalRef.current)
progressRef.current = [0, 0, 0]
setProgress([0, 0, 0])
setStatus('idle')
}
function handleRefresh() {
progressRef.current = [0, 0, 0]
setProgress([0, 0, 0])
setStatus('uploading')
}
function startUpload() {
progressRef.current = [0, 0, 0]
setProgress([0, 0, 0])
setStatus('uploading')
}
const isDone = status === 'complete'
const isPaused = status === 'paused'
const cardBg = isDark ? '#262623' : '#f1f1f0'
const titleColor = isDark ? '#f1f1ec' : '#1a1a18'
const mutedColor = isDark ? '#9a9a94' : '#6c6c6c'
const btnBg = isDark ? '#34342f' : '#ededea'
const btnColor = isDark ? '#b8b8b0' : '#6c6c6c'
const dividerColor = isDark ? '#34342f' : '#e4e4dc'
const trackColor = isDark ? '#34342f' : '#e4e4dc'
const subtitle = isDone
? 'Upload complete'
: isPaused
? `${overallPct}% · Paused`
: `${overallPct}% · ${secondsLeft}s left`
return (
<div ref={rootRef} className="flex min-h-screen w-full items-center justify-center bg-[#E8E8DF] px-4 dark:bg-[#1A1A19]">
<div className="w-full max-w-[480px]">
<AnimatePresence mode="wait">
{status === 'idle' ? (
<motion.div
key="idle"
initial={{ opacity: 0, scale: 0.96 }}
animate={{ opacity: 1, scale: 1 }}
exit={{ opacity: 0, scale: 0.96 }}
transition={SPRING}
className="flex justify-center"
>
<motion.button
onClick={startUpload}
whileHover={{ scale: 1.05 }}
whileTap={{ scale: 0.95 }}
transition={SPRING}
style={{
backgroundColor: isDark ? '#f1f1f0' : '#1a1a18',
color: isDark ? '#1a1a18' : '#f1f1f0',
borderRadius: 9999,
boxShadow: '0 4px 8px rgba(0,0,0,0.12)',
}}
className="px-7 py-3.5 font-sans text-[15px] font-bold"
>
Upload Files
</motion.button>
</motion.div>
) : (
<motion.div
key="card"
initial={{ opacity: 0, y: 12, scale: 0.97 }}
animate={{ opacity: 1, y: 0, scale: 1 }}
exit={{ opacity: 0, y: -8, scale: 0.97 }}
transition={SPRING}
style={{
backgroundColor: cardBg,
borderRadius: 28,
boxShadow: CARD_SHADOW,
overflow: 'hidden',
position: 'relative',
}}
>
{/* Header */}
<div className="flex items-start justify-between px-6 pt-5 pb-4">
<div className="min-w-0 flex-1 pr-3">
<h2
style={{ color: titleColor }}
className="font-sans text-[18px] font-bold leading-tight"
>
{isDone ? 'Upload complete' : `Uploading ${FILES.length} files`}
</h2>
<AnimatePresence mode="wait" initial={false}>
{!expanded && (
<motion.p
key={status}
initial={{ opacity: 0, y: 3 }}
animate={{ opacity: 1, y: 0 }}
exit={{ opacity: 0, y: -3 }}
transition={{ duration: 0.15 }}
style={{ color: mutedColor }}
className="mt-0.5 whitespace-nowrap font-sans text-[14px] font-medium"
>
{isDone ? 'Upload complete' : (
<>
<span className="inline-block min-w-[2.5rem] tabular-nums">
{overallPct}%
</span>
{' · '}
{isPaused ? 'Paused' : `${secondsLeft}s left`}
</>
)}
</motion.p>
)}
</AnimatePresence>
</div>
{/* Action buttons */}
<div className="flex shrink-0 items-center gap-1.5 pt-0.5">
{/* Group 1: Pause/Play + Refresh — hidden when complete */}
<AnimatePresence initial={false}>
{!isDone && (
<motion.div
key="upload-controls-left"
initial={{ opacity: 0, scale: 0.8 }}
animate={{ opacity: 1, scale: 1 }}
exit={{ opacity: 0, scale: 0.8 }}
transition={SPRING}
className="flex items-center gap-1.5"
>
{/* 1. Pause / Play */}
<IconBtn onClick={togglePause} bg={btnBg} color={btnColor}>
<AnimatePresence mode="wait" initial={false}>
{isPaused ? (
<motion.span
key="play-icon"
initial={{ opacity: 0, scale: 0.6 }}
animate={{ opacity: 1, scale: 1 }}
exit={{ opacity: 0, scale: 0.6 }}
transition={SPRING}
className="flex"
>
<Play size={15} weight="regular" />
</motion.span>
) : (
<motion.span
key="pause-icon"
initial={{ opacity: 0, scale: 0.6 }}
animate={{ opacity: 1, scale: 1 }}
exit={{ opacity: 0, scale: 0.6 }}
transition={SPRING}
className="flex"
>
<Pause size={15} weight="regular" />
</motion.span>
)}
</AnimatePresence>
</IconBtn>
{/* 2. Refresh */}
<IconBtn onClick={handleRefresh} bg={btnBg} color={btnColor}>
<ArrowCounterClockwise size={15} weight="regular" />
</IconBtn>
</motion.div>
)}
</AnimatePresence>
{/* 3. Expand / Collapse — always visible */}
<IconBtn
onClick={() => setExpanded(e => !e)}
bg={btnBg}
color={btnColor}
>
<AnimatePresence mode="wait" initial={false}>
{expanded ? (
<motion.span
key="collapse-icon"
initial={{ opacity: 0, scale: 0.6 }}
animate={{ opacity: 1, scale: 1 }}
exit={{ opacity: 0, scale: 0.6 }}
transition={SPRING}
className="flex"
>
<ArrowsInSimple size={15} weight="regular" />
</motion.span>
) : (
<motion.span
key="expand-icon"
initial={{ opacity: 0, scale: 0.6 }}
animate={{ opacity: 1, scale: 1 }}
exit={{ opacity: 0, scale: 0.6 }}
transition={SPRING}
className="flex"
>
<ArrowsOutSimple size={15} weight="regular" />
</motion.span>
)}
</AnimatePresence>
</IconBtn>
{/* Group 2: Stop / Close — hidden when complete */}
<AnimatePresence initial={false}>
{!isDone && (
<motion.div
key="close-control"
initial={{ opacity: 0, scale: 0.8 }}
animate={{ opacity: 1, scale: 1 }}
exit={{ opacity: 0, scale: 0.8 }}
transition={SPRING}
className="flex items-center"
>
{/* 4. Stop / Close */}
<IconBtn onClick={handleStop} bg={btnBg} color={btnColor}>
<X size={15} weight="regular" />
</IconBtn>
</motion.div>
)}
</AnimatePresence>
</div>
</div>
{/* Expanded file list */}
<AnimatePresence initial={false}>
{expanded && (
<motion.div
key="file-list"
initial={{ opacity: 0, height: 0 }}
animate={{ opacity: 1, height: 'auto' }}
exit={{ opacity: 0, height: 0 }}
transition={{
height: { type: 'spring', stiffness: 380, damping: 38 },
opacity: { duration: 0.16 },
}}
>
<div
style={{
height: 1,
backgroundColor: dividerColor,
marginLeft: 24,
marginRight: 24,
}}
/>
{FILES.map((f, i) => {
const pct = Math.round(progress[i])
const secs = Math.max(
0,
Math.round(((100 - progress[i]) / 100) * f.durationMs / 1000)
)
const fsub = isDone
? 'Complete'
: isPaused
? `${pct}% · Paused`
: `${pct}% · ${secs}s left`
return (
<div key={f.name} className="px-6 py-3">
<div className="flex items-center justify-between gap-3">
<span
style={{ color: titleColor }}
className="min-w-0 truncate font-sans text-[15px] font-bold"
>
{f.name}
</span>
<span
style={{ color: mutedColor }}
className="shrink-0 whitespace-nowrap font-sans text-[13px] font-medium"
>
{fsub}
</span>
</div>
<div
style={{ backgroundColor: trackColor }}
className="mt-2 h-[3px] overflow-hidden rounded-full"
>
<motion.div
className="h-full rounded-full"
animate={{
width: `${progress[i]}%`,
backgroundColor: isPaused ? '#f59e0b' : '#6366f1',
}}
transition={{
width: { duration: 0.08, ease: 'linear' },
backgroundColor: { duration: 0.35, ease: 'easeOut' },
}}
/>
</div>
</div>
)
})}
<div className="h-2" />
</motion.div>
)}
</AnimatePresence>
{/* Collapsed bottom progress bar */}
<AnimatePresence initial={false}>
{!expanded && (
<motion.div
key="bottom-bar"
initial={{ opacity: 0 }}
animate={{ opacity: 1 }}
exit={{ opacity: 0 }}
transition={{ duration: 0.15 }}
>
<div style={{ backgroundColor: trackColor, height: 6, overflow: 'hidden' }}>
<motion.div
className="h-full relative overflow-hidden"
animate={{
width: `${overallPct}%`,
backgroundColor: isPaused ? '#f59e0b' : '#6366f1',
}}
transition={{
width: { duration: 0.08, ease: 'linear' },
backgroundColor: { duration: 0.35, ease: 'easeOut' },
}}
>
<motion.div
className="absolute inset-y-0 w-1/2"
style={{ background: 'linear-gradient(to right, transparent, rgba(255,255,255,0.35), transparent)' }}
animate={{ x: isPaused ? '-100%' : ['-100%', '250%'] }}
transition={isPaused
? { duration: 0 }
: { duration: 1.6, repeat: Infinity, ease: 'linear', repeatDelay: 0.8 }
}
/>
</motion.div>
</div>
</motion.div>
)}
</AnimatePresence>
</motion.div>
)}
</AnimatePresence>
</div>
</div>
)
}
function IconBtn({
onClick,
bg,
color,
children,
}: {
onClick: () => void
bg: string
color: string
children: React.ReactNode
}) {
return (
<motion.button
onClick={onClick}
whileHover={{ scale: 1.12 }}
whileTap={{ scale: 0.88 }}
transition={{ type: 'spring', stiffness: 420, damping: 28 }}
style={{ backgroundColor: bg, color }}
className="flex size-9 items-center justify-center rounded-full"
>
{children}
</motion.button>
)
}
Add to your project
One command adds this component to your project.
Run the following command. New project? Run npx shadcn@latest init first to set up Tailwind and path aliases.
npx shadcn@latest add @aicanvas/upload-progressFor dark mode, add the dark class to your <html> element:
<html class="dark">Install with AI Canvas MCP
With AI Canvas MCP, your AI knows every component we ship. Ask for “a navigation component from AI Canvas” inside Claude Code, Codex, or Cursor and it can suggest you a few options, then install the one you like. Less typing, lower token cost, modern way to build.
Get MCPAbout Upload Progress
Upload Progress is a collapsible file-upload widget anchored to the corner of a viewport. The top bar shows a shimmer progress bar that runs indigo while uploading and amber when paused, and the expanded state breaks out each file into its own row with per-file progress, time remaining, and controls for pause, resume, refresh, and stop. Motion handles the collapse, the shimmer sweep, and the row-level transitions. It is the right component for file managers, asset upload flows, deploy dashboards, and any UI with long-running background tasks.
