Radial ToolbarA radial context menu that fans out formatting tools around a centre button, with active toggle states and an animated label pill.
'use client'
// npm install @phosphor-icons/react framer-motion
import { useState, useLayoutEffect, useEffect, useRef } from 'react'
import { motion, AnimatePresence } from 'framer-motion'
import type { Icon as PhosphorIcon } from '@phosphor-icons/react'
import {
X,
TextB,
TextItalic,
TextUnderline,
TextStrikethrough,
LinkSimple,
Palette,
} from '@phosphor-icons/react'
const useIsomorphicLayoutEffect = typeof window !== 'undefined' ? useLayoutEffect : useEffect
// ─── Types & Constants ────────────────────────────────────────────────────────
interface Tool {
id: string
label: string
Icon: PhosphorIcon
}
const CX = 120
const CY = 120
const R_IN = 30 // exactly half the button diameter (60px / 2) — no gap
const R_OUT = 114
const R_ICON = 78
const GAP = 0
const TOOLS: Tool[] = [
{ id: 'bold', label: 'Bold', Icon: TextB },
{ id: 'italic', label: 'Italic', Icon: TextItalic },
{ id: 'under', label: 'Underline', Icon: TextUnderline },
{ id: 'strike', label: 'Strikethrough', Icon: TextStrikethrough },
{ id: 'link', label: 'Link', Icon: LinkSimple },
{ id: 'color', label: 'Color', Icon: Palette },
]
// ─── Geometry ─────────────────────────────────────────────────────────────────
const toRad = (d: number) => (d - 90) * (Math.PI / 180)
function wedgePath(startDeg: number, endDeg: number): string {
const s = toRad(startDeg + GAP)
const e = toRad(endDeg - GAP)
const x1 = CX + R_IN * Math.cos(s); const y1 = CY + R_IN * Math.sin(s)
const x2 = CX + R_OUT * Math.cos(s); const y2 = CY + R_OUT * Math.sin(s)
const x3 = CX + R_OUT * Math.cos(e); const y3 = CY + R_OUT * Math.sin(e)
const x4 = CX + R_IN * Math.cos(e); const y4 = CY + R_IN * Math.sin(e)
return `M${x1} ${y1}L${x2} ${y2}A${R_OUT} ${R_OUT} 0 0 1 ${x3} ${y3}L${x4} ${y4}A${R_IN} ${R_IN} 0 0 0 ${x1} ${y1}Z`
}
function iconXY(midDeg: number) {
const r = toRad(midDeg)
return { x: CX + R_ICON * Math.cos(r), y: CY + R_ICON * Math.sin(r) }
}
// ─── RadialToolbar ────────────────────────────────────────────────────────────
export default function RadialToolbar() {
const [open, setOpen] = useState(false)
const [hoveredId, setHover] = useState<string | null>(null)
const [activeId, setActive]= useState<string | null>(null)
const containerRef = useRef<HTMLDivElement>(null)
const [isDark, setIsDark] = useState(() => typeof window !== 'undefined' ? document.documentElement.classList.contains('dark') : false)
useIsomorphicLayoutEffect(() => {
const el = containerRef.current
if (!el) return
const check = () => {
const card = el.closest('[data-card-theme]')
setIsDark(card ? card.classList.contains('dark') : document.documentElement.classList.contains('dark'))
}
check()
const observer = new MutationObserver(check)
observer.observe(document.documentElement, { attributes: true, attributeFilter: ['class'] })
const cardWrapper = el.closest('[data-card-theme]')
if (cardWrapper) observer.observe(cardWrapper, { attributes: true, attributeFilter: ['class'] })
return () => observer.disconnect()
}, [])
const handleTool = (id: string) => setActive(p => p === id ? null : id)
const close = () => { setOpen(false); setActive(null); setHover(null) }
const labelTool = TOOLS.find(t => t.id === hoveredId) ?? TOOLS.find(t => t.id === activeId)
return (
<div ref={containerRef} className="relative flex min-h-screen w-full items-center justify-center" style={{ background: isDark ? '#0a0a0a' : '#F5F1EA' }}>
{/* ── Wheel — fades in around the persistent circle ─────────────────── */}
<AnimatePresence>
{open && (
<div className="absolute inset-0 flex items-center justify-center">
<motion.div
style={{
width: 240,
height: 240,
position: 'relative',
filter: 'drop-shadow(0 20px 48px rgba(0,0,0,0.7))',
}}
initial={{ opacity: 0 }}
animate={{ opacity: 1 }}
exit={{ opacity: 0 }}
transition={{ duration: 0.22, ease: 'easeOut' }}
>
<svg width={240} height={240} className="absolute inset-0">
<circle
cx={CX} cy={CY} r={R_OUT + 1}
fill="none"
stroke={isDark ? 'rgba(255,255,255,0.06)' : 'rgba(0,0,0,0.10)'}
strokeWidth={1}
/>
{TOOLS.map((tool, i) => {
const isH = hoveredId === tool.id
const isA = activeId === tool.id
return (
<path
key={tool.id}
d={wedgePath(i * 60, i * 60 + 60)}
style={{
fill: isA
? (isDark ? 'rgba(255,255,255,0.18)' : 'rgba(0,0,0,0.16)')
: isH
? (isDark ? 'rgba(255,255,255,0.14)' : 'rgba(0,0,0,0.10)')
: (isDark ? 'rgba(255,255,255,0.07)' : 'rgba(0,0,0,0.06)'),
stroke: isDark ? 'rgba(255,255,255,0.04)' : 'rgba(0,0,0,0.06)',
strokeWidth: 1,
transition: 'fill 0.18s ease',
cursor: 'pointer',
}}
onPointerEnter={() => setHover(tool.id)}
onPointerLeave={() => setHover(null)}
onClick={() => handleTool(tool.id)}
/>
)
})}
</svg>
{/* Icons */}
{TOOLS.map((tool, i) => {
const { x, y } = iconXY(i * 60 + 30)
const isH = hoveredId === tool.id
const isA = activeId === tool.id
return (
<motion.div
key={`icon-${tool.id}`}
className="absolute flex items-center justify-center"
style={{
left: x - 12,
top: y - 12,
width: 24,
height: 24,
pointerEvents: 'none',
}}
initial={{ opacity: 0, scale: 0.4 }}
animate={{ opacity: 1, scale: 1 }}
transition={{
type: 'spring',
stiffness: 320,
damping: 28,
delay: i * 0.035 + 0.05,
}}
>
<tool.Icon
size={18}
weight="regular"
color={isA ? (isDark ? '#ffffff' : '#110F0C') : isH ? (isDark ? '#e4e4e7' : '#2E2A24') : (isDark ? '#71717a' : '#9E9890')}
/>
</motion.div>
)
})}
</motion.div>
</div>
)}
</AnimatePresence>
{/* ── Persistent circle — always visible, only content inside animates ── */}
<motion.button
style={{
position: 'relative',
zIndex: 10,
width: 60,
height: 60,
borderRadius: '50%',
display: 'flex',
alignItems: 'center',
justifyContent: 'center',
cursor: 'pointer',
background: isDark ? 'rgba(255,255,255,0.07)' : 'rgba(0,0,0,0.05)',
border: `1px solid ${isDark ? 'rgba(255,255,255,0.14)' : 'rgba(0,0,0,0.14)'}`,
boxShadow: isDark
? '0 8px 32px rgba(0,0,0,0.5), inset 0 1px 0 rgba(255,255,255,0.1)'
: '0 8px 32px rgba(0,0,0,0.12), inset 0 1px 0 rgba(255,255,255,0.6)',
}}
whileHover={{ scale: 1.08 }}
whileTap={{ scale: 0.94 }}
onClick={open ? close : () => setOpen(true)}
>
<AnimatePresence mode="wait">
{!open ? (
/* EDIT label */
<motion.span
key="edit"
initial={{ opacity: 0, scale: 0.7 }}
animate={{ opacity: 1, scale: 1 }}
exit={{ opacity: 0, scale: 0.7 }}
transition={{ duration: 0.14, ease: 'easeOut' }}
style={{
fontFamily: 'var(--font-sans, sans-serif)',
fontSize: 11,
fontWeight: 700,
letterSpacing: '0.1em',
color: isDark ? '#e4e4e7' : '#2E2A24',
userSelect: 'none',
}}
>
EDIT
</motion.span>
) : (
/* X icon */
<motion.span
key="x-icon"
initial={{ opacity: 0, rotate: -90, scale: 0.4 }}
animate={{ opacity: 1, rotate: 0, scale: 1 }}
exit={{ opacity: 0, rotate: -90, scale: 0.4 }}
transition={{ type: 'spring', stiffness: 260, damping: 24 }}
style={{ display: 'flex' }}
>
<X size={16} weight="regular" color={isDark ? '#a1a1aa' : '#4A453F'} />
</motion.span>
)}
</AnimatePresence>
</motion.button>
{/* ── Label pill ────────────────────────────────────────────────────────── */}
<AnimatePresence>
{open && labelTool && (
<motion.div
key={labelTool.id}
className="pointer-events-none absolute flex items-center gap-1.5 rounded-full px-3 py-1.5"
style={{
top: 'calc(50% + 140px)',
left: '50%',
x: '-50%',
background: isDark ? 'rgba(255,255,255,0.06)' : 'rgba(0,0,0,0.05)',
border: `1px solid ${isDark ? 'rgba(255,255,255,0.1)' : 'rgba(0,0,0,0.10)'}`,
fontFamily: 'var(--font-sans, sans-serif)',
whiteSpace: 'nowrap',
}}
initial={{ opacity: 0, y: 8, scale: 0.9 }}
animate={{ opacity: 1, y: 0, scale: 1 }}
exit={{ opacity: 0, y: 4, scale: 0.95 }}
transition={{ type: 'spring', stiffness: 500, damping: 30 }}
>
<labelTool.Icon size={11} weight="regular" color={activeId === labelTool.id ? (isDark ? '#e4e4e7' : '#2E2A24') : (isDark ? '#71717a' : '#9E9890')} />
<span className="text-xs font-medium" style={{ color: isDark ? '#a1a1aa' : '#736D65' }}>{labelTool.label}</span>
{activeId === labelTool.id && (
<motion.span
className="h-1 w-1 rounded-full"
style={{ background: isDark ? '#ffffff' : '#1C1916' }}
initial={{ scale: 0 }}
animate={{ scale: 1 }}
transition={{ type: 'spring', stiffness: 600, damping: 20 }}
/>
)}
</motion.div>
)}
</AnimatePresence>
</div>
)
}
Add to your project
One command adds this component to your project.
Run the following command. New project? Run npx shadcn@latest init first to set up Tailwind and path aliases.
npx shadcn@latest add @aicanvas/radial-toolbarFor dark mode, add the dark class to your <html> element:
<html class="dark">Install with AI Canvas MCP
With AI Canvas MCP, your AI knows every component we ship. Ask for “a navigation component from AI Canvas” inside Claude Code, Codex, or Cursor and it can suggest you a few options, then install the one you like. Less typing, lower token cost, modern way to build.
Get MCPAbout Radial Toolbar
Radial Toolbar is a context menu that fans out a ring of formatting tools around a central button when activated, with toggle states for each tool and a small animated label pill that names whichever icon you hover. Motion drives both the fan-out and the toggle feedback, so every tap has a clean visual confirmation. It is the canonical pick for text editors, image-editing studios, mobile-first interaction tools, and any UI where pointer travel matters more than menu length.
