Spider WebAn organic silk web that breathes with a slow idle bow.
'use client'
import { useLayoutEffect, useEffect, useRef, useState } from 'react'
const useIsomorphicLayoutEffect = typeof window !== 'undefined' ? useLayoutEffect : useEffect
// ─── Config ───────────────────────────────────────────────────────────────────
const N_RADIALS = 24
const N_RINGS = 14
// Idle organic sway (slow, broad)
const SWAY_AMP = 3.5 // px — node drift amplitude
const SWAY_SPD = 0.00045 // time step per frame
// Idle strand bow — curves every string even at rest
const BOW_AMP = 6 // px — perpendicular bow amplitude
const BOW_SPD = 0.55 // how fast the bow oscillates per strand
// Node spring physics — cursor pushes nodes, they bounce back
const NODE_PUSH_R = 90 // px — cursor repels nodes within this radius
const NODE_PUSH_STR = 3.2 // push impulse strength
const SPRING_K = 0.07 // spring return stiffness
const SPRING_DAMP = 0.84 // velocity retention per frame (lower = more bouncy)
// Hover bezier push on strands (very subtle — let node movement do the heavy work)
const PUSH_RADIUS = 280 // px
const PUSH_MAX = 18 // px — gentle, not dramatic
// ─── Types ────────────────────────────────────────────────────────────────────
interface WebNode {
bx: number; by: number
phase: number // personal sway phase
// spring state — offset from sway position
sx: number; sy: number
svx: number; svy: number
}
interface Strand {
a: number; b: number
kind: 'radial' | 'ring'
ring: number
// precomputed for idle bow
bowPhase: number // avg of both node phases
bowPerpX: number // unit perpendicular X (rotated 90° from strand direction)
bowPerpY: number // unit perpendicular Y
}
// ─── Build geometry ───────────────────────────────────────────────────────────
function buildWeb(W: number, H: number): { nodes: WebNode[]; strands: Strand[] } {
const cx = W / 2
const cy = H / 2
const maxR = Math.sqrt(W * W + H * H) * 0.56
const nodes: WebNode[] = []
// Node 0 = center
nodes.push({ bx: cx, by: cy, phase: 0, sx: 0, sy: 0, svx: 0, svy: 0 })
for (let r = 1; r <= N_RINGS; r++) {
const baseR = maxR * (r / N_RINGS)
for (let s = 0; s < N_RADIALS; s++) {
const angle = s * (2 * Math.PI / N_RADIALS) - Math.PI / 2
const jitter = 1 + (Math.random() - 0.5) * 0.18
nodes.push({
bx: cx + Math.cos(angle) * baseR * jitter,
by: cy + Math.sin(angle) * baseR * jitter,
phase: Math.random() * Math.PI * 2,
sx: 0, sy: 0, svx: 0, svy: 0,
})
}
}
const strands: Strand[] = []
function addStrand(a: number, b: number, kind: 'radial' | 'ring', ring: number) {
const na = nodes[a], nb = nodes[b]
const dx = nb.bx - na.bx, dy = nb.by - na.by
const len = Math.sqrt(dx * dx + dy * dy) || 1
// Perpendicular: rotate strand direction 90°
strands.push({
a, b, kind, ring,
bowPhase: (na.phase + nb.phase) / 2,
bowPerpX: -dy / len,
bowPerpY: dx / len,
})
}
// Radial strands
for (let s = 0; s < N_RADIALS; s++) {
addStrand(0, 1 + s, 'radial', 1)
for (let r = 1; r < N_RINGS; r++) {
const ai = 1 + (r - 1) * N_RADIALS + s
const bi = 1 + r * N_RADIALS + s
addStrand(ai, bi, 'radial', r + 1)
}
}
// Ring strands
for (let r = 1; r <= N_RINGS; r++) {
for (let s = 0; s < N_RADIALS; s++) {
const ai = 1 + (r - 1) * N_RADIALS + s
const bi = 1 + (r - 1) * N_RADIALS + (s + 1) % N_RADIALS
addStrand(ai, bi, 'ring', r)
}
}
return { nodes, strands }
}
// ─── Theme ────────────────────────────────────────────────────────────────────
function detectDark(el: HTMLElement): boolean {
const w = el.closest('[data-card-theme]')
if (w) return w.classList.contains('dark')
return document.documentElement.classList.contains('dark')
}
// ─── Component ────────────────────────────────────────────────────────────────
export default function ParticleConstellation() {
const canvasRef = useRef<HTMLCanvasElement>(null)
const containerRef = useRef<HTMLDivElement>(null)
const mouseRef = useRef<{ x: number; y: number } | null>(null)
const webRef = useRef<{ nodes: WebNode[]; strands: Strand[] } | null>(null)
const rafRef = useRef<number>(0)
const [isDark, setIsDark] = useState(() => typeof window !== 'undefined' ? document.documentElement.classList.contains('dark') : false)
const isDarkRef = useRef(typeof window !== 'undefined' ? document.documentElement.classList.contains('dark') : false)
// ── Theme ──────────────────────────────────────────────────────────────────
useIsomorphicLayoutEffect(() => {
const el = containerRef.current
if (!el) return
const check = () => { const d = detectDark(el); setIsDark(d); isDarkRef.current = d }
check()
const mo = new MutationObserver(check)
mo.observe(document.documentElement, { attributes: true, attributeFilter: ['class'] })
const w = el.closest('[data-card-theme]')
if (w) mo.observe(w, { attributes: true, attributeFilter: ['class'] })
return () => mo.disconnect()
}, [])
// ── Main loop ──────────────────────────────────────────────────────────────
useIsomorphicLayoutEffect(() => {
const canvas = canvasRef.current
const container = containerRef.current
if (!canvas || !container) return
const ctx = canvas.getContext('2d')
if (!ctx) return
let alive = true
let time = 0
function resize() {
if (!canvas || !container) return
const dpr = window.devicePixelRatio || 1
const w = container.clientWidth
const h = container.clientHeight
canvas.width = w * dpr
canvas.height = h * dpr
canvas.style.width = `${w}px`
canvas.style.height = `${h}px`
ctx!.setTransform(dpr, 0, 0, dpr, 0, 0)
webRef.current = buildWeb(w, h)
}
resize()
const ro = new ResizeObserver(() => { if (alive) resize() })
ro.observe(container)
const mo = new MutationObserver(() => {
if (alive && container) isDarkRef.current = detectDark(container)
})
const wrapper = container.closest('[data-card-theme]')
if (wrapper) mo.observe(wrapper, { attributes: true, attributeFilter: ['class'] })
mo.observe(document.documentElement, { attributes: true, attributeFilter: ['class'] })
function tick() {
if (!alive || !canvas || !ctx) return
rafRef.current = requestAnimationFrame(tick)
time += SWAY_SPD
const mouse = mouseRef.current
const web = webRef.current
if (!web) return
const W = container!.clientWidth
const H = container!.clientHeight
// ── Update node spring physics ───────────────────────────────────────
for (const n of web.nodes) {
// Sway position (slow broad drift)
const swayX = n.bx + Math.sin(time * 1.1 + n.phase) * SWAY_AMP
const swayY = n.by + Math.cos(time * 0.9 + n.phase * 1.4) * SWAY_AMP
// Cursor repulsion impulse on the spring
if (mouse) {
const liveX = swayX + n.sx
const liveY = swayY + n.sy
const dx = liveX - mouse.x
const dy = liveY - mouse.y
const dist = Math.sqrt(dx * dx + dy * dy)
if (dist < NODE_PUSH_R && dist > 0.1) {
const force = (1 - dist / NODE_PUSH_R) * NODE_PUSH_STR
n.svx += (dx / dist) * force
n.svy += (dy / dist) * force
}
}
// Spring return toward zero offset + damping
n.svx += -n.sx * SPRING_K
n.svy += -n.sy * SPRING_K
n.svx *= SPRING_DAMP
n.svy *= SPRING_DAMP
n.sx += n.svx
n.sy += n.svy
}
// ── Compute live positions ───────────────────────────────────────────
const pos = web.nodes.map(n => ({
x: n.bx + Math.sin(time * 1.1 + n.phase) * SWAY_AMP + n.sx,
y: n.by + Math.cos(time * 0.9 + n.phase * 1.4) * SWAY_AMP + n.sy,
}))
// ── Draw ─────────────────────────────────────────────────────────────
const dark = isDarkRef.current
const fg = dark ? '255,255,255' : '28,25,22'
ctx.clearRect(0, 0, W, H)
ctx.fillStyle = dark ? '#110F0C' : '#F5F1EA'
ctx.fillRect(0, 0, W, H)
ctx.lineCap = 'round'
ctx.lineJoin = 'round'
for (const s of web.strands) {
const pa = pos[s.a]
const pb = pos[s.b]
const mx = (pa.x + pb.x) / 2
const my = (pa.y + pb.y) / 2
// ── Always-on idle bow — never a straight line ─────────────────
const bow = BOW_AMP * Math.sin(time * BOW_SPD * 60 + s.bowPhase)
let cpx = mx + s.bowPerpX * bow
let cpy = my + s.bowPerpY * bow
// ── Subtle additional push on hover (small, additive) ──────────
if (mouse) {
const cdx = mouse.x - mx
const cdy = mouse.y - my
const cdist2 = cdx * cdx + cdy * cdy
const cdist = Math.sqrt(cdist2)
const falloff = Math.exp(-cdist2 / (PUSH_RADIUS * PUSH_RADIUS))
const bend = PUSH_MAX * falloff
if (cdist > 0.1) {
cpx -= (cdx / cdist) * bend
cpy -= (cdy / cdist) * bend
}
}
// ── Opacity ────────────────────────────────────────────────────
const depthFade = 1 - (s.ring - 1) / (N_RINGS + 2)
let alpha = s.kind === 'radial' ? 0.42 * depthFade : 0.20 * depthFade
if (mouse) {
const cdx = mouse.x - mx, cdy = mouse.y - my
const proximity = Math.exp(-(cdx * cdx + cdy * cdy) / (PUSH_RADIUS * PUSH_RADIUS * 0.35))
alpha = alpha * (1 - proximity * 0.82)
}
ctx.strokeStyle = `rgba(${fg},${alpha.toFixed(3)})`
ctx.lineWidth = s.kind === 'radial' ? 0.75 : 0.5
ctx.beginPath()
ctx.moveTo(pa.x, pa.y)
ctx.quadraticCurveTo(cpx, cpy, pb.x, pb.y)
ctx.stroke()
}
// ── Nodes ───────────────────────────────────────────────────────────
for (let i = 0; i < pos.length; i++) {
const p = pos[i]
let alpha = i === 0 ? 0.45 : 0.16
if (mouse) {
const dx = mouse.x - p.x, dy = mouse.y - p.y
const prox = Math.exp(-(dx * dx + dy * dy) / (160 * 160))
alpha = alpha * (1 - prox * 0.82)
}
ctx.beginPath()
ctx.arc(p.x, p.y, i === 0 ? 1.8 : 1.1, 0, Math.PI * 2)
ctx.fillStyle = `rgba(${fg},${alpha.toFixed(3)})`
ctx.fill()
}
}
rafRef.current = requestAnimationFrame(tick)
function onMove(e: MouseEvent) {
const rect = canvas!.getBoundingClientRect()
mouseRef.current = { x: e.clientX - rect.left, y: e.clientY - rect.top }
}
function onLeave() { mouseRef.current = null }
container.addEventListener('mousemove', onMove)
container.addEventListener('mouseleave', onLeave)
return () => {
alive = false
cancelAnimationFrame(rafRef.current)
ro.disconnect()
mo.disconnect()
container.removeEventListener('mousemove', onMove)
container.removeEventListener('mouseleave', onLeave)
}
}, [])
return (
<div
ref={containerRef}
className="relative min-h-screen w-full overflow-hidden"
style={{ background: isDark ? '#110F0C' : '#F5F1EA' }}
>
<canvas ref={canvasRef} className="absolute inset-0 h-full w-full" />
</div>
)
}
Add to your project
One command adds this component to your project.
Run the following command. New project? Run npx shadcn@latest init first to set up Tailwind and path aliases.
npx shadcn@latest add @aicanvas/particle-constellationFor dark mode, add the dark class to your <html> element:
<html class="dark">Install with AI Canvas MCP
With AI Canvas MCP, your AI knows every component we ship. Ask for “a navigation component from AI Canvas” inside Claude Code, Codex, or Cursor and it can suggest you a few options, then install the one you like. Less typing, lower token cost, modern way to build.
Get MCPAbout Spider Web
Spider Web is an organic silk lattice that bows gently on its own, with a slow idle motion so it never looks static. As you move across it, the nodes near your cursor are physically pushed outward and bounce back with internal tension, while the strings closest to you fade slightly so the focal point feels lifted. The whole composition is canvas-rendered with hand-tuned spring constants, no third-party physics required. It is built for editorial heroes, story-driven landing pages, and any layout where the background should feel like a living material.
