Slice TypeA typographic magic trick.
'use client'
// npm install framer-motion react
import { useEffect, useLayoutEffect, useRef, useState } from 'react'
import {
animate,
motion,
useMotionValue,
useSpring,
useTransform,
} from 'framer-motion'
import type { MotionValue } from 'framer-motion'
// The component is always in NIGHT mode at rest — dark bg, light text.
// On hover it inverts to LIGHT mode in sync with the word reveal.
const DARK_BG = '#0A0A0A'
const LIGHT_BG = '#EFEEE6'
const DARK_FG = '#EFEEE6'
const LIGHT_FG = '#0A0A0A'
// Measures how many pixels of "air" (side-bearing) sit between a character's
// advance-width origin and its leftmost ink pixel by rasterising to a canvas.
// Returns a positive number when the ink starts after the origin (normal LSB),
// 0 on any error. Re-runs on resize so it adapts to font-size changes.
function measureLeftInk(char: string, font: string): number {
try {
const W = 200, H = 200
const canvas = document.createElement('canvas')
canvas.width = W
canvas.height = H
const ctx = canvas.getContext('2d')
if (!ctx) return 0
ctx.font = font
ctx.textBaseline = 'alphabetic'
ctx.fillStyle = '#000'
ctx.fillText(char, 50, 150) // start drawing at x=50
const { data } = ctx.getImageData(0, 0, W, H)
for (let x = 0; x < W; x++) {
for (let y = 0; y < H; y++) {
if (data[(y * W + x) * 4 + 3] > 32) return x - 50
}
}
return 0
} catch {
return 0
}
}
function mix(a: string, b: string, t: number): string {
const pa = parseInt(a.slice(1), 16)
const pb = parseInt(b.slice(1), 16)
const ar = (pa >> 16) & 0xff; const ag = (pa >> 8) & 0xff; const ab = pa & 0xff
const br = (pb >> 16) & 0xff; const bg = (pb >> 8) & 0xff; const bb = pb & 0xff
const r = Math.round(ar + (br - ar) * t)
const g = Math.round(ag + (bg - ag) * t)
const bl = Math.round(ab + (bb - ab) * t)
return `#${((r << 16) | (g << 8) | bl).toString(16).padStart(6, '0')}`
}
// Two words that share a trailing skeleton — when clipped at the midline
// and overlaid, the shared letters align and only the leading glyph forms
// a hybrid. Swap these to make any other pair work.
const WORD_TOP = 'LIGHT'
const WORD_BOTTOM = 'NIGHT'
// How far the two words translate apart when fully open, as a fraction of
// their own height. 0.65 gives a visible gap between them.
const OPEN_OFFSET = 0.65
// Intro teaser — plays once on mount to show users what's possible.
const INTRO_DELAY_MS = 700
const INTRO_HOLD_MS = 1100
const INTRO_PEAK = 0.7
const INTRO_DURATION_S = 0.9
export default function SliceType() {
const rootRef = useRef<HTMLDivElement>(null)
const [reducedMotion, setReducedMotion] = useState(false)
useEffect(() => {
if (typeof window === 'undefined') return
const mq = window.matchMedia('(prefers-reduced-motion: reduce)')
const update = () => setReducedMotion(mq.matches)
update()
mq.addEventListener('change', update)
return () => mq.removeEventListener('change', update)
}, [])
// Engagement: 0 = aligned hybrid (rest), 1 = words fully separated.
const engage = useMotionValue(0)
const engageSmooth = useSpring(engage, { stiffness: 140, damping: 18, mass: 0.9 })
// Background and text color invert in sync with the reveal:
// engage=0 → NIGHT (dark bg, light text), engage=1 → LIGHT (light bg, dark text).
const bgColor = useTransform(engageSmooth, (e) => mix(DARK_BG, LIGHT_BG, e))
const fgColor = useTransform(engageSmooth, (e) => mix(DARK_FG, LIGHT_FG, e))
// Top word clip + vertical shift.
const topClip = useTransform(engageSmooth, (e) =>
`inset(0 0 ${50 * (1 - e)}% 0)`,
)
const topY = useTransform(engageSmooth, (e) => `${-OPEN_OFFSET * 100 * e}%`)
// Bottom word — mirror.
const botClip = useTransform(engageSmooth, (e) =>
`inset(${50 * (1 - e)}% 0 0 0)`,
)
const botY = useTransform(engageSmooth, (e) => `${OPEN_OFFSET * 100 * e}%`)
// L lives in its own absolutely-positioned wrapper pinned to the container's
// LEFT edge. IGHT lives in its own wrapper pinned to the RIGHT edge. At rest,
// the space between them is real layout space — L starts at the same x as
// NIGHT's N, producing a single continuous vertical stroke across the seam.
// When the hybrid opens, the L translates right to its natural position so
// the top word reads "LIGHT" cleanly.
const containerRef = useRef<HTMLDivElement>(null)
const lRef = useRef<HTMLSpanElement>(null)
const ightRef = useRef<HTMLSpanElement>(null)
// Measured distance (px) from the container's left edge to where L sits
// when the word is fully open (touching IGHT) and the alignment nudge that
// corrects for the side-bearing difference between N and L.
const naturalLeftMV: MotionValue<number> = useMotionValue(0)
const nudgeMV: MotionValue<number> = useMotionValue(0)
useLayoutEffect(() => {
const container = containerRef.current
const lEl = lRef.current
const ightEl = ightRef.current
if (!container || !lEl || !ightEl) return
const measure = () => {
const cRect = container.getBoundingClientRect()
const lRect = lEl.getBoundingClientRect()
const iRect = ightEl.getBoundingClientRect()
naturalLeftMV.set(Math.max(0, iRect.left - cRect.left - lRect.width))
// Measure the ink-level left edge for L and N at the current font so the
// nudge is accurate on every screen size and device (desktop vs mobile
// render at different sizes, giving different side-bearing differences).
const computed = window.getComputedStyle(lEl)
const font = `900 ${computed.fontSize} ${computed.fontFamily}`
const lInk = measureLeftInk('L', font)
const nInk = measureLeftInk('N', font)
// Both characters start at x=0 of the container. To make L's ink land on
// N's ink, translate L by (nInk − lInk).
nudgeMV.set(nInk - lInk)
}
measure()
const ro = new ResizeObserver(measure)
ro.observe(container)
return () => ro.disconnect()
}, [naturalLeftMV, nudgeMV])
// At rest, L sits at nudgeMV so its vertical stroke aligns with N's ink.
// At full open, L reaches naturalLeftMV so it snaps next to IGHT.
const lX = useTransform(
[engageSmooth, naturalLeftMV, nudgeMV],
([e, natural, nudge]) => {
const eN = e as number
return `${(nudge as number) * (1 - eN) + (natural as number) * eN}px`
},
)
// Intro teaser on first mount — self-demonstrates the interaction.
const didIntro = useRef(false)
useEffect(() => {
if (didIntro.current) return
if (reducedMotion) {
didIntro.current = true
return
}
didIntro.current = true
let cancelled = false
let closeTimer: ReturnType<typeof setTimeout> | null = null
const startTimer = setTimeout(async () => {
if (cancelled) return
const opener = animate(engage, INTRO_PEAK, {
duration: INTRO_DURATION_S,
ease: [0.22, 1, 0.36, 1],
})
try {
await opener
} catch {
/* animation cancelled */
}
if (cancelled) return
closeTimer = setTimeout(() => {
if (cancelled) return
animate(engage, 0, {
duration: INTRO_DURATION_S,
ease: [0.32, 0, 0.36, 1],
})
}, INTRO_HOLD_MS)
}, INTRO_DELAY_MS)
const cancel = () => {
cancelled = true
clearTimeout(startTimer)
if (closeTimer) clearTimeout(closeTimer)
}
cancelTeaserRef.current = cancel
return cancel
}, [engage, reducedMotion])
// Touch state — tap once to open, tap again to close.
const touchOpenRef = useRef(false)
// Cancel the intro teaser the moment the user first interacts, so their
// deliberate tap/hover isn't overridden by the teaser's return animation.
const cancelTeaserRef = useRef<(() => void) | null>(null)
const cancelTeaser = () => {
cancelTeaserRef.current?.()
cancelTeaserRef.current = null
}
const handlePointerEnter = (e: React.PointerEvent) => {
if (e.pointerType !== 'mouse') return
cancelTeaser()
engage.set(1)
}
const handlePointerLeave = (e: React.PointerEvent) => {
if (e.pointerType !== 'mouse') return
// Only close if touch hasn't toggled the component open.
engage.set(0)
}
const handlePointerDown = (e: React.PointerEvent) => {
if (e.pointerType === 'mouse') return
// Touch / pen: tap toggles the open state.
cancelTeaser()
touchOpenRef.current = !touchOpenRef.current
engage.set(touchOpenRef.current ? 1 : 0)
}
const sharedTextStyle: React.CSSProperties = {
fontFamily: 'ui-sans-serif, system-ui, -apple-system, "Segoe UI", sans-serif',
fontWeight: 900,
fontSize: 'clamp(3.5rem, 18vw, 11rem)',
lineHeight: 0.92,
letterSpacing: '-0.04em',
color: 'inherit',
whiteSpace: 'nowrap',
userSelect: 'none',
}
// The IGHT tail — its characters are identical between LIGHT and NIGHT so
// they align automatically when both are right-anchored.
const TAIL = WORD_TOP.slice(1)
return (
<motion.div
ref={rootRef}
className="flex min-h-screen w-full items-center justify-center overflow-hidden"
style={{ backgroundColor: bgColor, color: fgColor, touchAction: 'manipulation', cursor: 'pointer' }}
onPointerEnter={handlePointerEnter}
onPointerLeave={handlePointerLeave}
onPointerDown={handlePointerDown}
>
<div
ref={containerRef}
className="relative"
aria-label={`${WORD_TOP} / ${WORD_BOTTOM}`}
>
{/* Spacer — sizes the container to the wider word (NIGHT). */}
<span aria-hidden style={{ ...sharedTextStyle, visibility: 'hidden' }}>
{WORD_BOTTOM}
</span>
{/* Top word wrapper — carries the clip-path + vertical lift. */}
<motion.div
aria-hidden
style={{
position: 'absolute',
inset: 0,
clipPath: topClip,
WebkitClipPath: topClip,
y: topY,
willChange: 'transform, clip-path',
}}
>
{/* L — pinned left at rest, translates right on engage. */}
<motion.span
ref={lRef}
style={{
...sharedTextStyle,
position: 'absolute',
top: 0,
left: 0,
x: lX,
willChange: 'transform',
}}
>
{WORD_TOP.charAt(0)}
</motion.span>
{/* IGHT — pinned right, matches NIGHT's IGHT exactly. */}
<span
ref={ightRef}
style={{
...sharedTextStyle,
position: 'absolute',
top: 0,
right: 0,
}}
>
{TAIL}
</span>
</motion.div>
{/* Bottom word: NIGHT, right-aligned, clipped to its lower half. */}
<motion.span
aria-hidden
style={{
...sharedTextStyle,
position: 'absolute',
inset: 0,
textAlign: 'right',
clipPath: botClip,
WebkitClipPath: botClip,
y: botY,
willChange: 'transform, clip-path',
}}
>
{WORD_BOTTOM}
</motion.span>
</div>
</motion.div>
)
}
Add to your project
One command adds this component to your project.
Run the following command. New project? Run npx shadcn@latest init first to set up Tailwind and path aliases.
npx shadcn@latest add @aicanvas/slice-typeFor dark mode, add the dark class to your <html> element:
<html class="dark">Install with AI Canvas MCP
With AI Canvas MCP, your AI knows every component we ship. Ask for “a navigation component from AI Canvas” inside Claude Code, Codex, or Cursor and it can suggest you a few options, then install the one you like. Less typing, lower token cost, modern way to build.
Get MCPAbout Slice Type
Slice Type is a typographic magic trick: at rest you read one ambiguous word, but as you hover the letters slice horizontally — LIGHT lifting up, NIGHT sinking down — and the shared glyphs resolve into two separate words. The split is driven by Motion handling the vertical translations, with a canvas layer for the gradient masking that makes the cut feel clean. Use it for hero sections, brand sites, and editorial layouts where the headline itself is the surprise.
