Halo TypeRotating 3D ring text animation — the front arc reads upright, the back arc upside-down.
Typography3D & ShadersHero sectionType specimenEditorial
Switch to light
Refresh
Full screen
COPY ✦ PASTE ✦ SHIP ✦ REPEAT ✦
CCOOPPYY ✦✦ PPAASSTTEE ✦✦ SSHHIIPP ✦✦ RREEPPEEAATT ✦✦ CCOOPPYY ✦✦ PPAASSTTEE ✦✦ SSHHIIPP ✦✦ RREEPPEEAATT ✦✦
'use client'
// npm install framer-motion react
import React, { useEffect, useLayoutEffect, useRef, useState } from 'react'
import {
motion,
useAnimationFrame,
useMotionValue,
useSpring,
useTransform,
} from 'framer-motion'
// ─── Swap this to customise the ring text ─────────────────────────────────────
const PHRASE = 'COPY ✦ PASTE ✦ SHIP ✦ REPEAT ✦ '
// Static tilt + interaction tuning
const TILT_REST = 24 // rotateX at rest — a flat-ish ellipse
const TILT_HOVER = 24 // rotateX while hovered — no tilt change on hover
const SECONDS_PER_TURN = 14 // full rotation duration
const SPEED_HOVER = 0.3 // hover slows spin to 30%
const RADIUS_FRACTION = 0.35 // ring radius ≈ 35% of min(w, h) → diameter ≈ 70%
const STAR_SCALE = 0.65 // ✦ separators render smaller than letters
// ─── Local theme hook — observes `dark` class on <html> ──────────────────────
function useTheme(ref: React.RefObject<HTMLElement | null>) {
const [theme, setTheme] = useState<'light' | 'dark'>('dark')
useEffect(() => {
const element = ref.current
if (!element) return
const read = () => {
const scope = element.closest('[data-card-theme]') as HTMLElement | null
if (scope) {
setTheme(scope.dataset.cardTheme === 'dark' ? 'dark' : 'light')
return
}
setTheme(document.documentElement.classList.contains('dark') ? 'dark' : 'light')
}
read()
const observers: MutationObserver[] = []
let current: HTMLElement | null = element
while (current) {
const o = new MutationObserver(read)
o.observe(current, { attributes: true, attributeFilter: ['class', 'data-card-theme'] })
observers.push(o)
current = current.parentElement
}
return () => observers.forEach((o) => o.disconnect())
}, [ref])
return { theme }
}
export default function HaloType() {
const rootRef = useRef<HTMLDivElement>(null)
const wrapRef = useRef<HTMLDivElement>(null)
const { theme } = useTheme(rootRef)
const isDark = theme === 'dark'
// Container size → drives radius + font-size
const [size, setSize] = useState(480)
useLayoutEffect(() => {
const el = wrapRef.current
if (!el) return
const measure = () => {
const rect = el.getBoundingClientRect()
setSize(Math.max(260, Math.min(rect.width, rect.height)))
}
measure()
const ro = new ResizeObserver(measure)
ro.observe(el)
return () => ro.disconnect()
}, [])
// Reduced motion — freeze at a pleasing angle so both arcs are still visible.
const [reducedMotion, setReducedMotion] = useState(false)
useEffect(() => {
if (typeof window === 'undefined') return
const mq = window.matchMedia('(prefers-reduced-motion: reduce)')
const update = () => setReducedMotion(mq.matches)
update()
mq.addEventListener('change', update)
return () => mq.removeEventListener('change', update)
}, [])
// Hover / touch state drives a smoothly-interpolated "engagement" value in [0, 1].
const engagement = useMotionValue(0)
const engagementSmooth = useSpring(engagement, {
stiffness: 120,
damping: 22,
mass: 0.6,
})
// Tilt + spin-speed multiplier derive from engagement.
const tilt = useTransform(engagementSmooth, [0, 1], [TILT_REST, TILT_HOVER])
const speedMul = useTransform(engagementSmooth, [0, 1], [1, SPEED_HOVER])
// Continuous Y-rotation via MotionValue — no useState for animation values.
const rotateY = useMotionValue(0)
const prevTs = useRef<number | null>(null)
// Refs to each rendered glyph so the per-frame loop can fade them smoothly
// near the ±90° seam — a hard `backface-visibility` cutoff shows pixel-shred
// artifacts at near-perpendicular angles.
const frontRefs = useRef<Array<HTMLSpanElement | null>>([])
const backRefs = useRef<Array<HTMLSpanElement | null>>([])
// Geometry
const radius = size * RADIUS_FRACTION
const fontSize = Math.max(20, Math.min(48, radius * 0.22))
const circumference = 2 * Math.PI * radius
// Measure each PHRASE character's rendered width using a hidden DOM node +
// Range API. Matches the live glyph rendering (font, kerning, subpixel)
// exactly — canvas measureText can drift from DOM layout.
const [phraseWidths, setPhraseWidths] = useState<number[]>([])
const measureRef = useRef<HTMLSpanElement>(null)
useLayoutEffect(() => {
if (typeof document === 'undefined') return
const el = measureRef.current
if (!el) return
const measure = () => {
const spans = el.querySelectorAll<HTMLSpanElement>('[data-m-char]')
if (!spans.length) return
const widths = Array.from(spans).map((s) => s.getBoundingClientRect().width)
setPhraseWidths(widths)
}
measure()
// Re-measure whenever any child's rendered size changes — this catches
// the moment a late-loading webfont swaps in and fixes advance widths
// the fallback font got wrong.
const ro = new ResizeObserver(measure)
ro.observe(el)
const fonts = (document as Document & { fonts?: FontFaceSet }).fonts
if (fonts?.ready) {
fonts.ready.then(measure)
}
return () => ro.disconnect()
}, [fontSize])
// Tile the phrase around the ring, proportional to measured widths.
const phraseWidth = phraseWidths.reduce((a, b) => a + b, 0)
const repeats = phraseWidth > 0
? Math.max(1, Math.round(circumference / phraseWidth))
: Math.max(1, Math.round(circumference / (PHRASE.length * fontSize * 0.55)))
const characters = PHRASE.repeat(repeats).split('')
const totalChars = characters.length
const totalTiledWidth = phraseWidth * repeats
// Per-character center angles (proportional spacing). Falls back to equal
// spacing on the very first render before measurement lands.
const charAngles: number[] = []
if (totalTiledWidth > 0) {
let cum = 0
characters.forEach((_, i) => {
const w = phraseWidths[i % PHRASE.length] ?? 0
charAngles.push(((cum + w / 2) / totalTiledWidth) * 360)
cum += w
})
} else {
for (let i = 0; i < totalChars; i++) {
charAngles.push((i / totalChars) * 360)
}
}
// Advance the spin + update per-letter opacity each frame. Opacity is a
// smooth cos() of each letter's effective angle vs. camera — the front
// twin fades out and the back twin fades in as letters rotate past the
// perpendicular, with no hard cutoff artifacts.
useAnimationFrame((t) => {
if (reducedMotion) {
rotateY.set(30)
} else {
const last = prevTs.current
prevTs.current = t
if (last != null) {
const dt = (t - last) / 1000
const degPerSec = 360 / SECONDS_PER_TURN
const next = rotateY.get() + degPerSec * speedMul.get() * dt
rotateY.set(next % 360)
}
}
const ry = rotateY.get()
for (let i = 0; i < charAngles.length; i++) {
const eff = ((ry + charAngles[i]) % 360 + 360) % 360
const norm = eff > 180 ? eff - 360 : eff
const c = Math.cos((norm * Math.PI) / 180)
const frontOp = c > 0 ? c : 0
const backOp = c < 0 ? -c : 0
const fe = frontRefs.current[i]
const be = backRefs.current[i]
if (fe) fe.style.opacity = String(frontOp)
if (be) be.style.opacity = String(backOp)
}
})
// Colours — raw hex only; no design tokens inside the component.
const bg = isDark ? '#0A0A0A' : '#F5F1E8'
const fg = isDark ? '#F5F1E8' : '#0A0A0A'
// Back-arc letters are rendered upside-down (not mirror-flipped) via a twin
// glyph facing inward. They get a dimmer hue so the front arc stays hero.
const fgBack = isDark ? '#7A756C' : '#6A655C'
const vignette = isDark
? 'radial-gradient(60% 60% at 50% 52%, rgba(245,241,232,0.10) 0%, rgba(245,241,232,0.04) 35%, rgba(10,10,10,0) 70%)'
: 'radial-gradient(60% 60% at 50% 52%, rgba(10,10,10,0.08) 0%, rgba(10,10,10,0.03) 35%, rgba(245,241,232,0) 70%)'
// Shared pointer handlers — work for hover AND touch.
const handleEngage = () => engagement.set(1)
const handleRelease = () => engagement.set(0)
// Build the CSS transform for the ring container from two MotionValues.
const ringTransform = useTransform(
[tilt, rotateY],
([x, y]) => `rotateX(${x}deg) rotateY(${y}deg)`,
)
// Fade the extreme left/right edges of the stage so any residual seam
// pixels at the ±90° transition are masked cleanly. Long falloff so the
// corners are almost invisible.
const edgeMask =
'linear-gradient(to right, transparent 0%, black 18%, black 82%, transparent 100%)'
return (
<div
ref={rootRef}
className="flex min-h-screen w-full items-center justify-center"
style={{ backgroundColor: bg }}
>
<div
ref={wrapRef}
className="relative flex h-[min(100vh,100vw)] w-full items-center justify-center overflow-hidden"
style={{
touchAction: 'none',
maskImage: edgeMask,
WebkitMaskImage: edgeMask,
}}
onPointerEnter={handleEngage}
onPointerLeave={handleRelease}
onPointerDown={handleEngage}
onPointerUp={handleRelease}
onPointerCancel={handleRelease}
>
{/* Soft radial vignette behind the ring */}
<div
aria-hidden
style={{
position: 'absolute',
inset: 0,
background: vignette,
pointerEvents: 'none',
}}
/>
{/* Hidden per-character spans used to measure exact advance widths.
Each character gets its own inline-block sibling, styled the same
as the live glyph (including the smaller star size) so widths
match what renders on the ring. */}
<span
ref={measureRef}
aria-hidden
style={{
position: 'absolute',
top: 0,
left: 0,
visibility: 'hidden',
pointerEvents: 'none',
whiteSpace: 'pre',
fontFamily:
'ui-sans-serif, system-ui, -apple-system, "Segoe UI", sans-serif',
fontWeight: 800,
lineHeight: 1,
letterSpacing: '-0.01em',
}}
>
{PHRASE.split('').map((ch, i) => (
<span
key={i}
data-m-char=""
style={{
display: 'inline-block',
whiteSpace: 'pre',
fontSize: ch === '✦' ? fontSize * STAR_SCALE : fontSize,
}}
>
{ch}
</span>
))}
</span>
{/* Perspective stage */}
<div
style={{
perspective: '1200px',
perspectiveOrigin: '50% 50%',
width: size,
height: size,
position: 'relative',
}}
>
<motion.div
aria-label={PHRASE.trim()}
style={{
position: 'absolute',
inset: 0,
transformStyle: 'preserve-3d',
transform: ringTransform,
willChange: 'transform',
}}
>
{characters.map((ch, i) => {
const angle = charAngles[i] ?? (i / totalChars) * 360
const display = ch === ' ' ? ' ' : ch
const base = `translate(-50%, -50%) rotateY(${angle}deg) translateZ(${radius}px)`
const glyphSize = ch === '✦' ? fontSize * STAR_SCALE : fontSize
const glyphStyle: React.CSSProperties = {
position: 'absolute',
top: '50%',
left: '50%',
// Default transform-origin (center) is critical — with `0 0`
// (top-left), narrow letters end up at different 3D positions
// than wide letters at the same ring-angle, making the "I" in
// SHIP look like it's on a different plane.
transformOrigin: '50% 50%',
fontFamily:
'ui-sans-serif, system-ui, -apple-system, "Segoe UI", sans-serif',
fontWeight: 800,
fontSize: glyphSize,
lineHeight: 1,
letterSpacing: '-0.01em',
userSelect: 'none',
whiteSpace: 'pre',
}
return (
<React.Fragment key={i}>
{/* Front-facing glyph — visible on the front arc, upright.
Opacity is NOT set in the React style: the per-frame
loop manages it via ref so React re-renders (resize,
theme change) don't flash the letters to opacity 0. */}
<span
ref={(el) => {
frontRefs.current[i] = el
}}
style={{
...glyphStyle,
transform: base,
color: fg,
}}
>
{display}
</span>
{/* Inward-facing twin — visible on the back arc, rotated
180° in its own plane so it reads upside-down instead
of mirror-flipped. Dimmer hue. */}
<span
ref={(el) => {
backRefs.current[i] = el
}}
style={{
...glyphStyle,
transform: `${base} rotateY(180deg) rotateZ(180deg)`,
color: fgBack,
}}
>
{display}
</span>
</React.Fragment>
)
})}
</motion.div>
</div>
</div>
</div>
)
}
Add to your project
One command adds this component to your project.
1
Run the following command. New project? Run npx shadcn@latest init first to set up Tailwind and path aliases.
npx shadcn@latest add @aicanvas/halo-type2
For dark mode, add the dark class to your <html> element:
<html class="dark">Install with AI Canvas MCP
With AI Canvas MCP, your AI knows every component we ship. Ask for “a navigation component from AI Canvas” inside Claude Code, Codex, or Cursor and it can suggest you a few options, then install the one you like. Less typing, lower token cost, modern way to build.
Get MCPAbout Halo Type
Halo Type is a rotating 3D ring of text where the front arc reads upright and the back arc reads upside-down, with smooth perspective transitions as the ring spins. Motion drives the continuous rotation and the per-letter perspective transforms so the text always looks like it is on a real cylindrical surface. It is a striking pick for hero sections, type specimens, editorial covers, and any moment where the typography deserves to be the entire compositional event.
Built with
MotionTailwind CSS
AI Canvas
