Label CardsColour-blocked label cards scattered at random angles.
Native iOS & Android
Interaction Design
React & Next.js
Frontend Systems
Visual Identity
Brand Strategy
Magazine & Print
Typography Systems
Animation & Micro-UX
Interaction Patterns
tap a card to focus
'use client'
// npm install framer-motion
import { useRef, useState, useLayoutEffect, useEffect } from 'react'
import { motion } from 'framer-motion'
const useIsomorphicLayoutEffect = typeof window !== 'undefined' ? useLayoutEffect : useEffect
// ─── Base constants (designed at 480px container width) ──────────────────────
const BASE_CARD_W = 300
const BASE_CARD_H = 169 // 16:9
// ─── Card data ───────────────────────────────────────────────────────────────
const CARDS = [
{
id: 0,
title: 'Mobile Apps',
sub1: 'Native iOS & Android',
sub2: 'Interaction Design',
since: '2023',
bg: '#5CAD60',
fg: '#162217',
idle: { x: -82, y: -70, rotate: -11 },
},
{
id: 1,
title: 'Web Design',
sub1: 'React & Next.js',
sub2: 'Frontend Systems',
since: '2021',
bg: '#EDD540',
fg: '#241F05',
idle: { x: -48, y: 66, rotate: 9 },
},
{
id: 2,
title: 'Branding',
sub1: 'Visual Identity',
sub2: 'Brand Strategy',
since: '2020',
bg: '#1C2E8A',
fg: '#E8EDF8',
idle: { x: 12, y: -14, rotate: -4 },
},
{
id: 3,
title: 'Editorial',
sub1: 'Magazine & Print',
sub2: 'Typography Systems',
since: '2022',
bg: '#D43C3C',
fg: '#FAE8E8',
idle: { x: 68, y: 62, rotate: 14 },
},
{
id: 4,
title: 'Motion',
sub1: 'Animation & Micro-UX',
sub2: 'Interaction Patterns',
since: '2023',
bg: '#E08030',
fg: '#2A1A06',
idle: { x: 84, y: -86, rotate: 18 },
},
]
const BAR_PATTERN = [1,2,1,1,3,1,2,1,1,3,1,1,2,1,2,1,3,1,1,2,1,3,1,2,1,1,2,1]
const SPRING_SCATTER = { type: 'spring' as const, stiffness: 240, damping: 24 }
const SPRING_FOCUS = { type: 'spring' as const, stiffness: 340, damping: 28 }
// ─── Sub-components ───────────────────────────────────────────────────────────
function Barcode({ color, scale }: { color: string; scale: number }) {
return (
<div style={{ display: 'flex', alignItems: 'stretch', height: 28 * scale, gap: 1.2 * scale }}>
{BAR_PATTERN.map((w, i) => (
<div
key={i}
style={{ width: w * 1.5 * scale, background: color, opacity: 0.8, borderRadius: 0.5 }}
/>
))}
</div>
)
}
function LogoMark({ color, scale }: { color: string; scale: number }) {
const size = 28 * scale
return (
<div style={{ display: 'flex', flexDirection: 'column', alignItems: 'center', gap: 3 * scale }}>
<div
style={{
width: size,
height: size,
borderRadius: '50%',
border: `${1.5 * scale}px solid ${color}`,
display: 'flex',
alignItems: 'center',
justifyContent: 'center',
opacity: 0.85,
}}
>
<span style={{ fontSize: 7.5 * scale, fontWeight: 800, color, letterSpacing: '0.02em', lineHeight: 1 }}>
AI
</span>
</div>
<span style={{ fontSize: 6.5 * scale, fontWeight: 700, color, letterSpacing: '0.12em', textTransform: 'uppercase', opacity: 0.7 }}>
CANVAS
</span>
</div>
)
}
// ─── Component ────────────────────────────────────────────────────────────────
export default function LabelCards() {
const containerRef = useRef<HTMLDivElement>(null)
const [isDark, setIsDark] = useState(() => typeof window !== 'undefined' ? document.documentElement.classList.contains('dark') : false)
const [selected, setSelected] = useState<number | null>(null)
const [containerW, setContainerW] = useState(480)
useIsomorphicLayoutEffect(() => {
const el = containerRef.current
if (!el) return
// ── Theme detection ────────────────────────────────────────────────────────
const checkTheme = () => {
const card = el.closest('[data-card-theme]')
setIsDark(
card ? card.classList.contains('dark') : document.documentElement.classList.contains('dark'),
)
}
checkTheme()
const themeObs = new MutationObserver(checkTheme)
themeObs.observe(document.documentElement, { attributes: true, attributeFilter: ['class'] })
const cardWrapper = el.closest('[data-card-theme]')
if (cardWrapper) themeObs.observe(cardWrapper, { attributes: true, attributeFilter: ['class'] })
// ── Size tracking ──────────────────────────────────────────────────────────
const sizeObs = new ResizeObserver(entries => {
setContainerW(entries[0].contentRect.width)
})
sizeObs.observe(el)
return () => { themeObs.disconnect(); sizeObs.disconnect() }
}, [])
// ── Responsive scaling ─────────────────────────────────────────────────────
// Divide by 1.56 ensures the widest card (offset + half-width) stays in-frame
const cardW = Math.min(BASE_CARD_W, Math.floor(containerW / 1.56))
const cardH = Math.round(cardW * 9 / 16)
const scale = cardW / BASE_CARD_W
return (
<div
ref={containerRef}
className="relative flex min-h-screen w-full items-center justify-center overflow-hidden bg-[#E8E8DF] dark:bg-[#1A1A19]"
>
{/* Dot grid */}
<div
style={{
position: 'absolute',
inset: 0,
backgroundImage: `radial-gradient(circle, ${
isDark ? 'rgba(255,255,255,0.04)' : 'rgba(0,0,0,0.05)'
} 1px, transparent 1px)`,
backgroundSize: '28px 28px',
}}
/>
{CARDS.map(card => {
const isSelected = selected === card.id
return (
<motion.div
key={card.id}
style={{
position: 'absolute',
width: cardW,
height: cardH,
borderRadius: 10 * scale,
overflow: 'hidden',
cursor: 'pointer',
background: card.bg,
boxShadow: '0 10px 36px rgba(0,0,0,0.32)',
userSelect: 'none',
}}
animate={
isSelected
? { x: 0, y: 0, rotate: 0, scale: 1.05, zIndex: 10, opacity: 1 }
: {
x: card.idle.x * scale,
y: card.idle.y * scale,
rotate: card.idle.rotate,
scale: 1,
zIndex: 2,
opacity: 1,
}
}
transition={isSelected ? SPRING_FOCUS : SPRING_SCATTER}
onClick={() => setSelected(prev => (prev === card.id ? null : card.id))}
>
<div
style={{
height: '100%',
padding: `${12 * scale}px ${14 * scale}px ${11 * scale}px`,
display: 'flex',
flexDirection: 'column',
boxSizing: 'border-box',
}}
>
{/* Title row */}
<div
style={{
display: 'flex',
alignItems: 'center',
justifyContent: 'space-between',
marginBottom: 9 * scale,
}}
>
<div style={{ display: 'flex', alignItems: 'center', gap: 6 * scale }}>
<span style={{ fontSize: 16 * scale, fontWeight: 900, color: card.fg, lineHeight: 1, opacity: 0.9 }}>
✳
</span>
<span style={{ fontSize: 18 * scale, fontWeight: 800, color: card.fg, letterSpacing: '-0.025em', lineHeight: 1 }}>
{card.title}
</span>
</div>
<span style={{ fontSize: 9 * scale, fontWeight: 600, color: card.fg, opacity: 0.5, letterSpacing: '0.08em', textTransform: 'uppercase', whiteSpace: 'nowrap' }}>
Since {card.since}
</span>
</div>
{/* Divider */}
<div style={{ height: 1, background: card.fg, opacity: 0.22, marginBottom: 9 * scale, flexShrink: 0 }} />
{/* Body */}
<div style={{ flex: 1, display: 'flex', flexDirection: 'column', justifyContent: 'space-between' }}>
<div>
<p style={{ margin: 0, fontSize: 11.5 * scale, fontWeight: 600, color: card.fg, lineHeight: 1.35 }}>
{card.sub1}
</p>
<p style={{ margin: `${3 * scale}px 0 0`, fontSize: 11 * scale, fontWeight: 400, color: card.fg, opacity: 0.6, lineHeight: 1.35 }}>
{card.sub2}
</p>
</div>
{/* Bottom bar */}
<div style={{ display: 'flex', justifyContent: 'space-between', alignItems: 'flex-end' }}>
<Barcode color={card.fg} scale={scale} />
<LogoMark color={card.fg} scale={scale} />
</div>
</div>
</div>
</motion.div>
)
})}
{/* Hint */}
<motion.p
style={{
position: 'absolute',
bottom: 20,
fontSize: 11,
letterSpacing: '0.05em',
color: isDark ? 'rgba(255,255,255,0.2)' : 'rgba(0,0,0,0.2)',
pointerEvents: 'none',
}}
animate={{ opacity: selected !== null ? 0 : 1 }}
transition={{ duration: 0.3 }}
>
tap a card to focus
</motion.p>
</div>
)
}
Add to your project
One command adds this component to your project.
Run the following command. New project? Run npx shadcn@latest init first to set up Tailwind and path aliases.
npx shadcn@latest add @aicanvas/label-cardsFor dark mode, add the dark class to your <html> element:
<html class="dark">Install with AI Canvas MCP
With AI Canvas MCP, your AI knows every component we ship. Ask for “a navigation component from AI Canvas” inside Claude Code, Codex, or Cursor and it can suggest you a few options, then install the one you like. Less typing, lower token cost, modern way to build.
Get MCPAbout Label Cards
Label Cards is a scatter of color-blocked cards thrown at random angles across the canvas, like sticky notes on a corkboard. Tap any one and it springs to the centre, scales up, and rotates upright; tap again and it returns to the pile. Motion drives the spring-to-centre and the return path so the motion always feels physical. Use it for mood boards, branding showcases, design-system color directories, and empty states that want to feel like a creative workspace.
