// npm install class-variance-authority clsx tailwind-merge @carbon/icons-react
Root element must use min-h-screen.
The source ships h-full because AI Canvas renders it inside a sized preview frame. A standalone paste needs min-h-screen, or an ancestor with a real height, or the root collapses and takes its absolute layers with it.
Before building, verify your project has the following setup:
- React / Next.js
- TypeScript
- Tailwind CSS v4
If any are missing, set up via the shadcn CLI:
npx shadcn@latest init
---
Build a Andromeda Button — a sci-fi / blueprint-style button with shadcn-style variants, fully self-contained in a single file. The button should feel like it belongs on a dark mission-control UI: transparent fills, 1px hairline borders, electric-blue accent, JetBrains Mono uppercase label with wide letter-spacing.
## File structure
Single file: `andromeda-button.tsx`. No external component library except Radix Slot (`@radix-ui/react-slot`), cva (`class-variance-authority`), clsx, and tailwind-merge — all of which are already in most Next.js starters. Do not extract helpers into separate files.
## Required dependencies
- `react` (with `forwardRef`)
- `@radix-ui/react-slot` — for `asChild`
- `class-variance-authority` — for the variants object
- `clsx` + `tailwind-merge` — for the `cn` helper
- Tailwind CSS v4 (the button is fully styled via arbitrary-value Tailwind classes referencing CSS custom properties)
## Visual spec
Render a dark container (`background: #0E0E0F`) showing three buttons stacked vertically with 12px gap:
1. `<Button variant="default">Launch</Button>` — electric-blue accent fill, accent border, glow on hover
2. `<Button variant="outline">Cancel</Button>` — transparent, white hairline border, subtle raised surface on hover
3. `<Button variant="ghost" size="sm">Learn more</Button>` — no border, label only, subtle background on hover
## Variants (cva)
5 variants × 3 sizes. Every state expressed as Tailwind arbitrary-value classes referencing `var(--andromeda-...)` custom properties. The properties are emitted onto the button's own style prop by a helper `andromedaVars()` (below), so each button is self-contained.
Variants:
- `default` — text `var(--andromeda-accent-base)`, bg `var(--andromeda-accent-glow-soft)`, border `var(--andromeda-accent-dim)`, hover brightens everything and adds a 16px glow shadow
- `outline` — text `var(--andromeda-text-primary)`, bg `var(--andromeda-surface-raised)`, border `var(--andromeda-border-base)`, hover surface + brighter border
- `ghost` — transparent bg & border, text `var(--andromeda-text-secondary)`, hover brightens text and fills background
- `destructive` — red-tinted version of default, uses `var(--andromeda-fault-*)` tokens
- `link` — transparent, accent text, underline on hover, no focus ring
Sizes:
- `sm` — px-3 py-[5px], text-[10px]
- `md` — px-4 py-2, text-[12px]
- `lg` — px-5 py-[11px], text-[14px]
Default variants: `variant: 'default'`, `size: 'md'`.
## Tokens (inline in the file)
Put this at the top of the file and spread its return value onto each button's `style` prop via `{...andromedaVars(), ...style}`:
```ts
const andromedaVars = () => ({
'--andromeda-text-primary': 'rgba(255,255,255,0.96)',
'--andromeda-text-secondary': 'rgba(255,255,255,0.62)',
'--andromeda-surface-raised': 'rgba(255,255,255,0.025)',
'--andromeda-surface-hover': 'rgba(255,255,255,0.06)',
'--andromeda-surface-active': 'rgba(255,255,255,0.09)',
'--andromeda-border-base': 'rgba(255,255,255,0.08)',
'--andromeda-border-bright': 'rgba(255,255,255,0.32)',
'--andromeda-accent-base': '#60A5FA',
'--andromeda-accent-bright': '#93C5FD',
'--andromeda-accent-dim': 'rgba(96,165,250,0.55)',
'--andromeda-accent-glow': 'rgba(96,165,250,0.18)',
'--andromeda-accent-glow-soft': 'rgba(96,165,250,0.08)',
'--andromeda-fault': '#EF4444',
'--andromeda-fault-dim': 'rgba(239,68,68,0.50)',
'--andromeda-fault-glow':'rgba(239,68,68,0.10)',
'--andromeda-fault-ring':'rgba(239,68,68,0.25)',
'--andromeda-font-mono': "'JetBrains Mono', 'IBM Plex Mono', Menlo, Monaco, monospace",
'--andromeda-weight-medium': '500',
'--andromeda-tracking-wider': '0.14em',
'--andromeda-leading-tight': '1.1',
'--andromeda-radius-none': '0',
'--andromeda-2': '8px',
'--andromeda-3': '12px',
'--andromeda-4': '16px',
'--andromeda-5': '20px',
}) as React.CSSProperties
```
## Structural classes (applied to every variant)
```
'relative inline-flex items-center justify-center select-none whitespace-nowrap'
'gap-[var(--andromeda-2)] border border-solid rounded-[var(--andromeda-radius-none)]'
'[font-family:var(--andromeda-font-mono)] font-[number:var(--andromeda-weight-medium)]'
'uppercase [letter-spacing:var(--andromeda-tracking-wider)] [line-height:var(--andromeda-leading-tight)]'
'cursor-pointer transition-all duration-150 ease-out active:scale-[0.97]'
'[backdrop-filter:blur(2px)] [-webkit-backdrop-filter:blur(2px)]'
'focus-visible:outline-none focus-visible:shadow-[0_0_0_1px_var(--andromeda-accent-dim),0_0_12px_var(--andromeda-accent-glow)]'
'disabled:cursor-not-allowed disabled:opacity-[0.35] disabled:pointer-events-none'
```
## API shape
```ts
export const Button = forwardRef<HTMLButtonElement, ButtonProps>(function Button(
{ className, variant = 'default', size = 'md', asChild = false, icon: Icon, children, style, type = 'button', ...props },
ref,
) { ... })
```
- `asChild: boolean` — when true, renders via Radix Slot (merges props/styles into the only child)
- `icon?: React.ComponentType<{ size?: number }>` — optional icon component rendered before children; size 16/18/20 for sm/md/lg
- All other `ButtonHTMLAttributes<HTMLButtonElement>` are passed through via `...props`
## Page wrapper
Render the demo with `JetBrains_Mono` from `next/font/google` (variable: `--font-jetbrains-mono`). Put the font's `.variable` className on the root container so the `--andromeda-font-mono` token resolves to the loaded font.
## Checklist before you finish
- [ ] The file has `'use client'` at the top
- [ ] `andromedaVars()` is spread onto every button's `style` prop (so tokens cascade without a context)
- [ ] All three size steps work (sm/md/lg)
- [ ] Hover on the default variant brightens text, background, border AND adds a blue glow shadow
- [ ] Focus-visible shows a 1px accent ring + 12px accent glow (not a browser default outline)
- [ ] `active:scale-[0.97]` is present
- [ ] `asChild` with a single `<a>` child renders an anchor, not a button, with the same styles
## Typography
- Font: JetBrains Mono
- Sizes: 10px, 12px, 14px
