'use client'
// npm install framer-motion react
// font: Anton
import { useEffect, useRef, useState } from 'react'
import React from 'react'
import {
animate,
useMotionValue,
useMotionValueEvent,
} from 'framer-motion'
import type { AnimationPlaybackControls, MotionValue } from 'framer-motion'
// ─── WildMorph ────────────────────────────────────────────────────────────────
// Single full-viewport panel with one centered italic "wild" word on a warm
// off-white surface. The cursor's vertical position over the panel decides
// which warp engages:
//
// • Cursor in the UPPER half → top-corner warp: TL & TR pull up + outward;
// bottom corners stay pinned. Transform-origin '0 100%' (bottom edge).
// • Cursor in the LOWER half → bottom-corner warp: BL & BR pull down +
// outward; top corners stay pinned. Transform-origin '0 0' (top edge).
// • Cursor leaves the panel → all eight corner offsets ease back to 0.
//
// Crossing the midline mid-hover animates the active warp out to identity and
// the opposite warp in to its extreme — both transitions fire from the same
// onPointerMove handler, debounced by a `mode` ref so we only re-tween when
// the mode actually changes.
//
// Technique: CSS `transform: matrix3d(...)` driven by a 2D quad-to-quad
// homography computed per-frame from eight motion values (one X + one Y per
// corner). The source rect [(0,0),(w,0),(w,h),(0,h)] is always mapped onto
// the target quad built from those eight offsets.
const DARK_BG = '#1a1a19'
const LIGHT_BG = '#efeee6'
function useTheme(ref: React.RefObject<HTMLElement | null>) {
const [theme, setTheme] = useState<'light' | 'dark'>('dark')
useEffect(() => {
const element = ref.current
if (!element) return
const readTheme = () => {
const cardScope = element.closest('[data-card-theme]') as HTMLElement | null
if (cardScope) {
setTheme(cardScope.dataset.cardTheme === 'dark' ? 'dark' : 'light')
return
}
setTheme(document.documentElement.classList.contains('dark') ? 'dark' : 'light')
}
readTheme()
const observers: MutationObserver[] = []
let current: HTMLElement | null = element
while (current) {
const observer = new MutationObserver(readTheme)
observer.observe(current, { attributes: true, attributeFilter: ['class', 'data-card-theme'] })
observers.push(observer)
current = current.parentElement
}
return () => observers.forEach((o) => o.disconnect())
}, [ref])
return { theme }
}
// Spring config for enter/cross: underdamped so corners overshoot and
// oscillate 2-3 times like a heavy mass snapping into place.
const ENTER_SPRING = { type: 'spring', stiffness: 280, damping: 14, mass: 1.8 } as const
// Spring config for release: same mass/stiffness, slightly more damping so
// the return oscillates but settles back to rest a touch more gently.
const RETURN_SPRING = { type: 'spring', stiffness: 280, damping: 16, mass: 1.8 } as const
// ── Homography (corner-pin) math ──────────────────────────────────────────────
// Given four target corners [tl, tr, br, bl] and the container's natural
// dimensions (w, h), compute the CSS matrix3d string that warps the natural
// rect [(0,0),(w,0),(w,h),(0,h)] onto that target quadrilateral.
//
// Derivation: we want a 3x3 projective matrix H such that for each source
// corner (uᵢ, vᵢ), H·(uᵢ, vᵢ, 1)ᵀ is homogeneous-equal to (xᵢ, yᵢ, 1)ᵀ. With
// H = [[a,c,e],[b,d,f],[g,h,1]] (bottom-right fixed to 1), each pair
// (source → target) gives two linear equations in the 8 unknowns
// (a,b,c,d,e,f,g,h):
//
// a·u + c·v + e − g·u·x − h·v·x = x
// b·u + d·v + f − g·u·y − h·v·y = y
//
// Four corner pairs → 8 equations → solve by Gaussian elimination. Then we
// embed H into a 4x4 CSS matrix3d (column-major), with the perspective
// components g, h placed in the w-row slots:
//
// matrix3d(
// a, b, 0, g,
// c, d, 0, h,
// 0, 0, 1, 0,
// e, f, 0, 1
// )
type Pt = readonly [number, number]
function solve8(
A: number[][], // 8x8
b: number[], // length 8
): number[] {
// Gaussian elimination with partial pivoting on an 8x9 augmented matrix.
const n = 8
const M: number[][] = A.map((row, i) => [...row, b[i]])
for (let col = 0; col < n; col++) {
// Partial pivot: find row with largest absolute value in this column.
let pivot = col
let maxAbs = Math.abs(M[col][col])
for (let r = col + 1; r < n; r++) {
const v = Math.abs(M[r][col])
if (v > maxAbs) {
maxAbs = v
pivot = r
}
}
if (maxAbs < 1e-12) {
// Degenerate quad (collinear corners). Fall back to identity contrib.
return [1, 0, 0, 1, 0, 0, 0, 0]
}
if (pivot !== col) {
const tmp = M[col]
M[col] = M[pivot]
M[pivot] = tmp
}
// Normalize pivot row.
const p = M[col][col]
for (let c = col; c <= n; c++) M[col][c] /= p
// Eliminate other rows.
for (let r = 0; r < n; r++) {
if (r === col) continue
const factor = M[r][col]
if (factor === 0) continue
for (let c = col; c <= n; c++) {
M[r][c] -= factor * M[col][c]
}
}
}
const x: number[] = new Array(n)
for (let i = 0; i < n; i++) x[i] = M[i][n]
return x
}
function cornerPinMatrix3d(
tl: Pt,
tr: Pt,
br: Pt,
bl: Pt,
w: number,
h: number,
): string {
// Source corners are the container's natural rect.
const src: readonly Pt[] = [
[0, 0],
[w, 0],
[w, h],
[0, h],
] as const
const dst: readonly Pt[] = [tl, tr, br, bl] as const
// Build the 8x8 system. Unknown order: [a, b, c, d, e, f, g, h].
const A: number[][] = []
const rhs: number[] = []
for (let i = 0; i < 4; i++) {
const [u, v] = src[i]
const [x, y] = dst[i]
// x-row: a·u + c·v + e − g·u·x − h·v·x = x
A.push([u, 0, v, 0, 1, 0, -u * x, -v * x])
rhs.push(x)
// y-row: b·u + d·v + f − g·u·y − h·v·y = y
A.push([0, u, 0, v, 0, 1, -u * y, -v * y])
rhs.push(y)
}
const [a, b, c, d, e, f, g, hh] = solve8(A, rhs)
// Embed the 3x3 homography into a 4x4 CSS matrix3d (column-major).
//
// matrix3d(
// a, b, 0, g,
// c, d, 0, h,
// 0, 0, 1, 0,
// e, f, 0, 1
// )
return `matrix3d(${a},${b},0,${g},${c},${d},0,${hh},0,0,1,0,${e},${f},0,1)`
}
// ── Hover targets ─────────────────────────────────────────────────────────────
// Multipliers of W / H; materialized into pixels at animation start from the
// container's real size. Deliberately asymmetric L/R (1.00 vs 1.05, 1.55 vs
// 1.48) so the stretched trapezoid doesn't feel mirror-perfect.
const X_OUTER_LEFT = -1.0 // mult of W — left column pulled hard outward (-X)
const X_OUTER_RIGHT = 1.05 // mult of W — right column pushed past the edge (+X)
const Y_LEFT_MAG = 1.55 // mult of H — left-corner vertical magnitude
const Y_RIGHT_MAG = 1.48 // mult of H — right-corner vertical magnitude
// Mode reflects which warp is currently engaged.
// 'none' — pointer outside; all 8 offsets = 0.
// 'top' — pointer in upper half; TL/TR pull UP (-Y) + outward.
// 'bottom' — pointer in lower half; BL/BR pull DOWN (+Y) + outward.
type Mode = 'none' | 'top' | 'bottom'
// The 8 corner offsets, in a fixed order matching the motion-value tuple
// the panel owns: [tlX, tlY, trX, trY, blX, blY, brX, brY].
type Offsets8 = readonly [
number,
number,
number,
number,
number,
number,
number,
number,
]
// Compute the target offset vector (in pixel space) for a given mode.
function targetsFor(mode: Mode, w: number, h: number): Offsets8 {
if (mode === 'top') {
return [
X_OUTER_LEFT * w, // tlX
-Y_LEFT_MAG * h, // tlY (UP)
X_OUTER_RIGHT * w, // trX
-Y_RIGHT_MAG * h, // trY (UP)
0,
0, // blX, blY pinned
0,
0, // brX, brY pinned
] as const
}
if (mode === 'bottom') {
return [
0,
0, // tlX, tlY pinned
0,
0, // trX, trY pinned
X_OUTER_LEFT * w, // blX
Y_LEFT_MAG * h, // blY (DOWN)
X_OUTER_RIGHT * w, // brX
Y_RIGHT_MAG * h, // brY (DOWN)
] as const
}
return [0, 0, 0, 0, 0, 0, 0, 0] as const
}
export default function WildMorph({ text = 'wild' }: { text?: string }) {
const containerRef = useRef<HTMLDivElement>(null)
const { theme } = useTheme(containerRef)
const isDark = theme === 'dark'
const bgColor = isDark ? DARK_BG : LIGHT_BG
const inkColor = isDark ? LIGHT_BG : DARK_BG
// Eight motion values — one X + one Y per corner. All start at 0 → identity
// matrix → static text.
const tlX: MotionValue<number> = useMotionValue(0)
const tlY: MotionValue<number> = useMotionValue(0)
const trX: MotionValue<number> = useMotionValue(0)
const trY: MotionValue<number> = useMotionValue(0)
const blX: MotionValue<number> = useMotionValue(0)
const blY: MotionValue<number> = useMotionValue(0)
const brX: MotionValue<number> = useMotionValue(0)
const brY: MotionValue<number> = useMotionValue(0)
// Container ref — where we write `style.transform` imperatively every frame.
const warpRef = useRef<HTMLDivElement>(null)
// Host of the hover / touch area.
const panelRef = useRef<HTMLDivElement>(null)
// SVG and text element refs for getBBox measurement.
const svgRef = useRef<SVGSVGElement>(null)
const textRef = useRef<SVGTextElement>(null)
// Natural (un-warped) container size in px. Stored in a ref so the matrix
// builder doesn't need a render to re-read it.
const sizeRef = useRef<{ w: number; h: number }>({ w: 1, h: 1 })
// Active animation controls, so a transition can cancel any in-flight tweens
// before firing fresh ones.
const controlsRef = useRef<AnimationPlaybackControls[]>([])
// Current mode — kept in a ref so the pointer-move handler can dedupe
// without triggering re-renders.
const modeRef = useRef<Mode>('none')
// Natural SVG bounding box dimensions, derived from getBBox().
// ascent = -getBBox().y (distance from baseline up to top of ink).
const [natural, setNatural] = useState({ width: 1, height: 1, ascent: 1 })
// Responsive font size — JS equivalent of clamp(4rem, 12vw, 9rem).
const [fontSize, setFontSize] = useState(144)
// Track responsive font size based on viewport width.
useEffect(() => {
const update = () => {
const vw = window.innerWidth
const clamped = Math.min(Math.max(vw * 0.12, 64), 144)
setFontSize(clamped)
}
update()
window.addEventListener('resize', update)
return () => window.removeEventListener('resize', update)
}, [])
// Re-measure the SVG text bounding box whenever fontSize or text changes.
useEffect(() => {
const el = textRef.current
if (!el) return
const bbox = el.getBBox()
if (bbox.width === 0) return
setNatural({
width: bbox.width,
height: bbox.height,
ascent: -bbox.y, // y is negative: distance from baseline up to top of ink
})
}, [fontSize, text])
// Build the matrix3d string from all 8 motion values and write it.
const applyTransform = () => {
const el = warpRef.current
if (!el) return
const { w, h } = sizeRef.current
const tl: Pt = [0 + tlX.get(), 0 + tlY.get()]
const tr: Pt = [w + trX.get(), 0 + trY.get()]
const br: Pt = [w + brX.get(), h + brY.get()]
const bl: Pt = [0 + blX.get(), h + blY.get()]
el.style.transform = cornerPinMatrix3d(tl, tr, br, bl, w, h)
}
// When natural dimensions update, sync sizeRef and recompute the transform.
useEffect(() => {
if (natural.width > 1 && natural.height > 1) {
sizeRef.current = { w: natural.width, h: natural.height }
applyTransform()
}
// applyTransform reads refs only; not a dep.
// eslint-disable-next-line react-hooks/exhaustive-deps
}, [natural])
// Measure natural size via ResizeObserver. The warp container keeps its
// intrinsic layout size (it's the transform that changes), so we can read
// offsetWidth / offsetHeight directly.
useEffect(() => {
const el = warpRef.current
if (!el) return
const update = () => {
const w = el.offsetWidth
const h = el.offsetHeight
if (w > 0 && h > 0) {
sizeRef.current = { w, h }
// Rebuild once with fresh dimensions (in case we're at rest with all
// offsets at 0, this still produces identity — which is correct).
applyTransform()
}
}
const ro = new ResizeObserver(update)
ro.observe(el)
update()
return () => ro.disconnect()
// applyTransform reads refs only; not a dep.
// eslint-disable-next-line react-hooks/exhaustive-deps
}, [])
// One subscription per motion value — all eight tick in the same animation
// frame, so any change event means the whole frame is ready to paint.
useMotionValueEvent(tlX, 'change', applyTransform)
useMotionValueEvent(tlY, 'change', applyTransform)
useMotionValueEvent(trX, 'change', applyTransform)
useMotionValueEvent(trY, 'change', applyTransform)
useMotionValueEvent(blX, 'change', applyTransform)
useMotionValueEvent(blY, 'change', applyTransform)
useMotionValueEvent(brX, 'change', applyTransform)
useMotionValueEvent(brY, 'change', applyTransform)
// ── Mode orchestration ─────────────────────────────────────────────────────
const stopAll = () => {
for (const c of controlsRef.current) c.stop()
controlsRef.current = []
}
// Apply a mode change: cancel in-flight tweens, switch transform-origin, and
// animate all 8 motion values to the target vector for the new mode.
const applyMode = (next: Mode) => {
if (next === modeRef.current) return
modeRef.current = next
// Always keep transform-origin at '0 0'. The matrix3d homography already
// pins the correct corners via the target quad — no origin trick needed.
// Using any other origin pre-shifts coordinates before the matrix, feeding
// out-of-domain inputs to the homography and causing wild extrapolation.
if (warpRef.current) {
warpRef.current.style.transformOrigin = '0 0'
}
stopAll()
const { w, h } = sizeRef.current
const targets = targetsFor(next, w, h)
// Faster, punchier curve when warping in / crossing; gentler easeOut on
// return to identity.
const opts = next === 'none' ? RETURN_SPRING : ENTER_SPRING
controlsRef.current = [
animate(tlX, targets[0], opts),
animate(tlY, targets[1], opts),
animate(trX, targets[2], opts),
animate(trY, targets[3], opts),
animate(blX, targets[4], opts),
animate(blY, targets[5], opts),
animate(brX, targets[6], opts),
animate(brY, targets[7], opts),
]
}
// Cleanup on unmount.
useEffect(() => {
return () => stopAll()
// eslint-disable-next-line react-hooks/exhaustive-deps
}, [])
// Derive mode from a clientY relative to the panel's bounding rect.
// Returns 'top' for upper half, 'bottom' for lower half, 'none' if outside.
const modeFromClientY = (clientY: number): Mode => {
const el = panelRef.current
if (!el) return 'none'
const rect = el.getBoundingClientRect()
if (clientY < rect.top || clientY > rect.bottom) return 'none'
return clientY < rect.top + rect.height / 2 ? 'top' : 'bottom'
}
// ── Pointer (mouse + pen) handlers ─────────────────────────────────────────
// Unified pointer handlers — covers mouse, touch, and pen in one path.
// setPointerCapture keeps move/up events firing even if pointer drifts outside.
const onPointerDown = (e: React.PointerEvent<HTMLDivElement>) => {
e.currentTarget.setPointerCapture(e.pointerId)
applyMode(modeFromClientY(e.clientY))
}
const onPointerMove = (e: React.PointerEvent<HTMLDivElement>) => {
applyMode(modeFromClientY(e.clientY))
}
const onPointerUp = () => applyMode('none')
const onPointerLeave = () => applyMode('none')
const onPointerCancel = () => applyMode('none')
return (
<div
ref={(el) => {
(containerRef as React.MutableRefObject<HTMLDivElement | null>).current = el;
(panelRef as React.MutableRefObject<HTMLDivElement | null>).current = el;
}}
className="relative flex min-h-screen w-full select-none items-center justify-center"
style={{
backgroundColor: bgColor,
perspective: '1400px',
perspectiveOrigin: '50% 50%',
cursor: 'crosshair',
touchAction: 'none',
}}
onPointerDown={onPointerDown}
onPointerMove={onPointerMove}
onPointerUp={onPointerUp}
onPointerLeave={onPointerLeave}
onPointerCancel={onPointerCancel}
>
<style>{`@import url('https://fonts.googleapis.com/css2?family=Anton&display=swap');`}</style>
<div
ref={warpRef}
className="relative"
style={{
transformOrigin: '0 0',
willChange: 'transform',
display: 'inline-block',
}}
>
<svg
ref={svgRef}
style={{ display: 'block', overflow: 'visible' }}
width={natural.width}
height={natural.height}
>
<text
ref={textRef}
x={0}
y={natural.ascent}
fontFamily='Anton, "Arial Narrow", Impact, sans-serif'
fontStyle="italic"
fontWeight={400}
fontSize={fontSize}
letterSpacing="-0.02em"
fill={inkColor}
>
{text}
</text>
</svg>
</div>
</div>
)
}
Add to your project
One command adds this component to your project.
1
Run the following command. New project? Run npx shadcn@latest init first to set up Tailwind and path aliases.
npx shadcn@latest add @aicanvas/wild-morph2
For dark mode, add the dark class to your <html> element:
<html class="dark">3
This component uses Anton. Add it to your project:
Optional<link href="https://fonts.googleapis.com/css2?family=Anton:wght@400;500;600;700;800&display=swap" rel="stylesheet">
